Optical vortices with a helical wavefront around the phase singularity and a doughnut-shaped intensity profile bring a new degree of light beams, i.e., orbital angular momentum (OAM). The unique physical properties of optical vortices have facilitated applications including optical manipulations of matters,1^,2 communications,3^,4 quantum entanglement,5^,6 and high-resolution imaging.7^,8 Nowadays, optical vortices can be produced even with fractional topological charge,9 which have attracted enormous attention in many fields owing to their unusual properties.10^,11 First, the fractional vortices featuring radially opening rings enable fine manipulations on particles or cells, i.e., transporting12 and controlled rotating.13 Subsequently, as fractional vortices can be decomposed into a series of integer vortices, it has been proven to improve the capacity of communications.14 Moreover, fractional vortices may be helpful in edge enhancement of optical imaging15^,16 and analyzing some physical processes, i.e., high-dimensional quantum entanglement17 and fractional flux quantum vortices in superconductors.18

On the other hand, the generation and application of vortices in the terahertz (THz) band have attracted increasing interest as it covers characteristic frequencies of many physical processes,19 rotational and vibrational energy levels of many molecules,20 and the near-future communication bands as well.21 Heretofore, THz vortices have already been employed to manipulate non-linearities in graphene,22 Bose–Einstein condensation currents,23 and biological macromolecules.24 In addition, THz vortices are found to be capable of reshaping electron bunches.25 Possible ways to generate THz vortices are to modulate the wavefronts of the THz beams by use of spiral phase plates,26 q-plates,27 or some diffractive optical elements.28^,29 However, it is not possible to tune the topological charge flexibly with fractional topological charges. Laser–plasma-based schemes are supposed to produce intense THz vortices with high tunability. For instance, THz vortices were generated from long plasma filaments excited with two-color optical vortices.30^,31 Besides, the interaction between optical vortices and spatially modulated plasmas may also lead to THz vortices.32 However, these laser–plasma schemes require complex manipulations both on the topological charges of the input lasers and the plasma structures. In general, there is a lack of effective means to generate THz vortices with tunable topological charges up to now.

Here, we present a way to generate intense THz radiation with continuously tunable topological by non-collinearly injecting a femtosecond laser pulse into a parabolic plasma channel. By adjusting the injection condition of the laser pulse, the trajectory of the laser centroid can be twisted into a cylindrical spiral with a constant radius. In this case, the laser ponderomotive force induces net currents in the radial direction. Due to the propagation effects of both THz radiation and laser pulses, the THz radiation at far field features with phase gradients wrapping around the propagation direction, leading to a THz vortex. By conducting three-dimensional (3D) particle-in-cell (PIC) simulations, it is proved that the topological charge of the THz radiation can be continuously tunable by only adjusting the injection conditions of the laser pulses. As the required laser pulses are only at the weakly relativistic level with the pulse energy of a few tens of mJ and the plasma channel can be produced with existing techniques, this plasma-based high-power THz vortex source can be realized with existing technologies.

It was demonstrated previously that ultrashort laser pulses can be well-guided in parabolic plasma channels with the plasma density profile n(r)=n0+Δnr2/r02.33^,34 Here, Δn and r0 are respectively the depth and width of the plasma channel. Once the laser pulse is non-collinearly injected into the channel, the trajectory of the laser beam centroid is a spiral around the channel axis.35 We notice that the beam centroid rotates in a cylindrical spiral with a fixed radius if the injection condition for the laser pulse meets z0cosθz=y0cosθy, where θy and θz are the angles between the injection direction and the coordinate axes y and z, respectively (see the Supplementary Material). The coordinate (y0,z0) is defined as the location of the laser pulse at the entrance of the plasma channel (or the vacuum–channel boundary). Therefore, the laser pulse can pass through a parabolic plasma channel in a cylindrical spiral with an injection condition of y0=0 and θz=π/2 with varied z0 and θy, as shown in Fig. 1(a). We keep this laser injection condition hereafter for convenience. In this case, the corresponding propagation period Λ0=2π|z0tanθy|, which is completely determined by z0 and θy. Meanwhile, the chirality of the laser trajectory is decided by the sign of z0tanθy. If z0tanθy>0, the laser rotates counterclockwise along the x-axis [as shown in Fig. 1(a)] and vice versa. Assume φ to be the azimuth angle in the y-z plane defined by φ=tan−1(z/y).

With a twisted trajectory as discussed above, the laser centroid keeps away from the channel center and spirals around the central axis of the plasma channel (x-axis) with the same radius rcen during propagation. We consider a weakly relativistic laser aL=a0exp(−rL2/W02)sin2[π(x−ct)/dL], where a0 is related to the peak laser intensity through Iλ02=a02·1.37×1018Wcm−2μm2, dL and W0 are respectively the duration and beam waists of the laser pulse, and rL=r−rcen is the radial coordinate from the laser centroid. At each position illuminated by the laser pulse, a transverse transient current ∂J⊥/∂t=−enc2aL2rL/W02 is excited due to the ponderomotive force36^,37Fp=−mec2∇aL2/4. Here, e, me, and c are the charge and mass of electrons, and the speed of light in a vacuum, respectively. Within each cross-section along the x-axis as shown in Fig. 1(c), the temporal rate of total transient current RJ(x)=∫∂J⊥/∂tdS is the spatial summation over the laser beam cross-section. Taking Fig. 1(c1) as an example, one can find that the y-direction component of RJ vanishes as the current in the upper half is equal to that of the lower half with the opposite polarity on rL. However, the z-direction component accumulates as the right half covers a higher plasma density. Therefore, RJ is aligned in the off-axis direction at each cross-section, which can be derived as RJ(x)=±RJ0(x)sin(2πΛ0x)y^+RJ0(x)cos(2πΛ0x)z^.(1)

Here, RJ0(x)=|RJ(x)| is the amplitude of the temporal rate of transient current, and y^ and z^ are the unit vectors. The sign of the first term, which is determined by the chirality of the trajectory, is positive if z0tanθy>0, and vice versa. Along with propagation of the laser pulse, the accumulated current at each position shall lead to a THz radiation38^,39ETHz∝RJ(x), which is polarized at the off-axis direction as well. To ensure that the THz pulses can radiate out of the channel, we consider a channel with a finite radius as shown in Fig. 1(b), where rc and rw are the channel radius and channel wall width, respectively. Such a density profile can be obtained experimentally with a tunable rc in the expansion process of laser-induced plasma waveguides.40^–42

To investigate the THz radiation as well as the laser dynamics in the plasma channel quantitatively, we conduct 3D PIC simulations using the code OSIRIS.43 The detailed simulation parameters are given in methods. The trajectories for laser beams propagating inside this plasma channel under two different laser injection conditions are shown in Fig. 2(a). It is clearly shown that the laser centroid follows a spiral trajectory around the channel axis. With the injection condition of z0=10λ0 and θy=88.5deg, the trajectory period for the laser spin inside the plasma channel is about Λ0=1.95mm, which agrees well with the calculated result of 1.92 mm. Under the laser injection condition of z0=10λ0 and θy=91.5deg, the calculated Λ0 keeps the same value, whereas the chirality of the laser trajectory is reversed clockwise following the sign of z0tanθy. The snapshots of the THz electric field around the plasma channel at x=0,Λ0/4,Λ0/2,3Λ0/4 under the laser injection condition of z0=10λ0 and θy=88.5deg are shown in Fig. 1(d). It is notable that the THz pulse radiates through the plasma-vacuum boundary close to the laser centroid with its polarization parallel to the off-axis direction of the laser centroid. The polarity of the THz radiation changes along the plasma channel. For example, it is reversed for THz emission from the plasma segments separated by Λ0/2 along the channel axis, as Fig. 1(d3) compared with Fig. 1(d1) and Fig. 1(d4) compared with Fig. 1(d2). This result is associated with the polarity reversal of RJ(x). Generally, one can say that THz radiation is radially polarized.

As given in previous studies,39 the spatial distribution of THz radiation induced by transverse transient current always keeps a cone. However, as the incident laser beam for driving the THz radiation is non-concentric with the plasma channel, the spatial distribution of the THz radiation is reformed due to its coupling with the plasma wave. As the skin depth of the THz radiation c/ωTHz is in the order of tens of microns, the spatial distribution of the emitted THz pulse is always following the off-axis direction of the beam centroid with respect to the channel center, as schematically shown in Fig. 1(c). The simulation result in Fig. 1(d) confirms our analysis. Provided that the laser beam propagates with a cylindrical spiral trajectory in the plasma channel, the THz pulse radiated from different segments of the channel rotates its radiation direction at far-field as shown in Fig. 1(a). In this case, the THz radiation at a specified azimuth angle φ (clockwise from the z-axis) at the far field is mapped to a specific position along the laser propagation. Therefore, the far-field radiation can be derived as dETHz(x,R,φ)∝RJ(x)δ(φ−σ2πxΛ0)·1ReikTHzR·eiΦ(x).(2)

Here, δ is the Dirac delta function, σ=z0tanθy/|z0tanθy|, with z0tanθy to define the chirality of the trajectory. kTHz is the wavevector of the THz radiation, R is the propagation distance to the far field, and Φ is the propagation phase of the THz radiation, which is introduced by the propagation effects of both the laser pulse and the THz radiation.

As for the laser pulse, the optical length dDlaser within a plasma segment dx along the propagation axis can be derived as dDlaser=Np1+(2πz0/Λ0)2dx,(3)where Np is the refractive index of the plasma channel for the laser beam at r=z0, and N0 is the vacuum refractive index for THz radiation. Considering that the plasma density is in the order of ∼1018cm−3, which is relatively low compared with the critical density of the drive laser in the order of ∼1021cm−3, we take the approximation of Np=N01−ωp2/ω2≈N0=1. Moreover, the oblique incident angle of the laser θy is close to π/2, and the off-axis position z0 should be within the beam radius for stable guiding.35 Therefore, we employ the first order of Taylor’s series in Eq. (3) with the fact that Λ0≫z0, and the optical length of the laser within a propagation period Λ0 can be derived as Dlaser=Λ0(1+1/2tan2θy). For the radiated THz pulse, it first propagates through the plasma area and then propagates rectilinearly with a radiation angle α [as marked in Fig. 1(a)] after leaving the side edge of the plasma channel. Considering that the critical density of the THz radiation is comparable to the plasma density, the refractive index of the plasma channel for the THz radiation is NpTHz(r)=N01−ωp2(r)/ωTHz2. The optical length of the THz radiation DTHz within a propagation period Λ0 can be approximated as DTHz=NpTHzd/sinα+N0(Λ0−d/tanα)/cosα,(4)where d=rc+rw−z0 is the transverse distance from the laser centroid to the channel boundary. Considering that different segments of the plasma channel contribute to THz radiation with different spatial angles in the y-z plane in Eq. (2), a continuous phase shift eiΦ(x) is introduced by spatial separation among THz components emitted from different plasma segments, resulting in a THz beam carrying OAM. Once the spatial delay within a propagation period Λ0 is comparable to the THz wavelength, the THz pulse should have a corresponding topological charge ℓ=−σDlaser−DTHzλTHz,(5)where λTHz is the peak wavelength of THz radiation. The phase shift now can be represented as Φ(x)=2πxℓ/Λ0. This result indicates that the topological charge of the THz radiation is just decided by the injection condition of the laser as λTHz is associated with z0.

Based on the above analysis, we reconstruct the THz field (see Figs. S1 and S2 in the Supplementary Material) and conduct 3D PIC simulations to examine the features of the THz pulse. To remove the laser field, the calculated electric field is lowpass filtered with the cutoff frequency at 100 THz. The radial component of THz electric field is extracted from the simulation results through ETHzR=ETHzysinφ+ETHzzcosφ. Note that the plasma density in the simulation is assumed to be pre-formed; therefore, neither plasma current nor Cherenkov radiation44^–46 is included. The simulated THz radiation under the injection condition of z0=10λ0 and θy=88.5deg is shown in Figs. 2(b)–2(d). The THz radiation from each plasma segment along the plasma channel emits at a given azimuth angle φ, forming a tornado-like wavefront as shown in Fig. 2(b). The central frequency of the THz radiation lies at ∼15.75THz with the corresponding wavelength of 19.05μm. The radiation angle is 5.3 deg as shown in Fig. 3(b). The calculated topological charge of the THz radiation according to Eq. (5) is ℓ=−0.95. As shown in the phase distribution of the THz radiation in Fig. 2(c), the THz radiation experiences a continuous phase gradient from φ=0 to 2π. Meanwhile, the phase singularity of the THz radiation is non-concentric with the plasma channel due to the fractional topological charge.36 The waveforms of the THz radiation at a radius of 100μm from the channel center [green dashed line in Fig. 2(c)] collected at different azimuth angles φ are shown in Fig. 2(d). It is notable that the THz waveform is endowed with a negative phase with an increase in angle φ, which agrees with a negative ℓ.

As discussed above, the topological charge ℓ can be totally determined by the laser injection conditions based upon Eq. (5). However, once the transverse position z0 is changed, the THz central wavelength λTHz and the radiation angle α changes as well following the plasma wavelength47 of πmc2/n(r)e2. By conducting a series of 3D PIC simulations, the spectra of the THz emission with laser excitation at different z0 are shown in Fig. 3(a). In the simulation, the channel radius is expanded simultaneously with z0 for the same amount to ensure that the laser is well-guided within the plasma channel. The extracted central frequency as well as the radiation angle of the THz radiation under different z0 is shown in Fig. 3(b), in which both parameters increase with increased z0. The central frequency of the THz radiation remains higher than the plasma frequency at the laser centroid position [blue solid line in Fig. 3(b)]. That is because the low-frequency components experience severe absorption along the propagation path to the plasma–vacuum boundary. As for the radiation angle, the refractive index has a sharper gradient transversely with higher plasma density with increased z0. Meanwhile, the refraction-induced radiation angle is enhanced.

Taking the variation in central frequency and radiation angle into account, ℓ can be obtained using Eq. (5) as blue lines in Fig. 3(c). When z0<W0, as the frequency of the THz radiation increases, the refractive index NpTHz is much lower than 1, leading to a much shorter DTHz and steadily increasing on the value of topological charge ℓ. However, as z0>W0 with linearly increasing Λ0, the increased radiation angle becomes non-negligible, leading to a severe increase on the second term of DTHz in Eq. (4). Therefore, the value of the topological charge saturates at around −2. Moreover, it is no longer applicable as z0>W0 accounting that the calculation [blue dashed line in Fig. 3(c)] employs paraxial approximation.35 To further increase the order of such THz vortices, one may increase z0, W0, and r0 at the same time.

Based on the above analysis, the order of topological charge on the THz radiation is continuously tunning from −2 to 2, with its chirality decided by the sign of z0tanθy. We now give a check on the tunning methods on the topological charge by simulations. Under smaller off-axis quantity conditions, i.e., z0+rc<c/ωp, the THz can radiate away from the channel at all angles as the distance from the laser centroid to the plasma boundaries is shorter than the skin depth of the THz radiation. The phase distribution of the THz radiation under the injection condition of z0=4μm is shown in Fig. 3(d), in which THz radiation nearly keeps the same phase with different azimuthal angles φ, indicating a tiny topological charge. When z0 is increased to 10μm, the calculated topological charge is ℓ=−1.93. In this case, the simulation result on the phase distribution of the THz radiation experiences a change of 4π as shown in Fig. 3(d).

As ℓ can be reversed by changing either the sign of z0 or tanθy as given in Eq. (5), we now change θy to 91.5 deg to flip the sign of tanθy while keeping z0 unchanged to get a positive ℓ. As discussed in Fig. 2(a), the chirality of the laser trajectory under this condition was reversed while changing θy. The simulation result on the THz phase distribution is shown in Fig. 3(e). Here, the THz radiation gets a positive phase gradient with increasing φ, which corresponds to a THz radiation carrying a reversed OAM compared with Fig. 2(c). These results demonstrate that the OAM of the THz radiation can be flexibly tuned by adjusting the laser injection condition.

As discussed in Fig. 1, the energy of the laser wakefield can be continuously converted into THz radiation along the twisted laser trajectory. The THz energy conversion efficiency with different propagation lengths L is shown in Fig. 3(f). When calculating this, we take only the magnetic field outside the plasma channel area into consideration and low-pass filter components with a frequency above 100 THz. The conversion efficiency here is calculated by dividing the magnetic field energy of the emitted THz emission in vacuum by the magnetic field energy of the input laser. It is shown that conversion efficiency saturates over 3×10−4 after propagating for several millimeters for the given off-axis z0=10λ0. Moreover, a larger off-axis distance z0 should lead to a stronger THz radiation. As given in Fig. 3(c) (blue line), the peak field strength reaches sub-GV/m under the condition of z0=16μm. In Fig. 2(a), it was shown that the laser trajectory radius keeps decreasing while propagating due to the loss of laser energy by exciting the wakefields. As the skin depth of the THz radiation c/ωTHz is in the order of tens of microns, the THz radiation vanishes while the trajectory is shrinking inside. As the off-axis quantity keeps decreasing, the conversion efficiency saturates with a longer propagation distance.

We propose a scheme to generate THz vortices with continuously tunable OAM by non-collinearly injecting a weakly relativistic ultrashort laser pulse into a parabolic plasma channel. Such a parabolic plasma channel can be realized experimentally through well-developed technologies, i.e., laser-induced plasma waveguides40^–42 or capillary discharges,36 and has been widely used in laser–plasma-based electron accelerators.48^,49 The trajectory of the laser beam can be twisted into a cylindrical spiral with a constant radius by manipulating the laser injection conditions. The asymmetric excitation of laser wakefields leads to THz radiation from the side boundary of the plasma channel into the vacuum. Theoretical analysis and 3D PIC simulations reveal that such a THz radiation carries OAM due to the difference in the optical paths between the laser inside the channel and the emitted THz radiation, where its topological charge can be continuously tuned from −2 to 2 by controlling the injection conditions of the injected laser pulse. 3D PIC simulations suggest that the THz vortex pulse can be generated with field strength up to sub-GV/m and energy conversion efficiency over 3×10−4 with femtosecond laser pulses at a few tens of mJ in energy. Intense THz vortices with fractional topological charges are unique, and their potential applications are yet to be studied. Such tornado-like electromagnetic pulses should also exist in other frequency bands and could be produced not only in laboratory but also in some astrophysical environments.

The 3D PIC simulations are conducted utilizing the code OSIRIS. In the moving frame, the size of the simulation box is X×Y×Z=100×440×320λ03 with total cells of 2000×880×640. Note that we rotate the plasma channel for θy instead of obliquely injecting the laser beam (see Fig. S3 in the Supplementary Material). In the simulation hereafter, all the results are shown in the channel coordinate for convenience. In the simulation, a0 is fixed at 0.5 (with the corresponding intensity of 5.35×1017W/cm2), and the laser beam radius W0 and duration dL are taken as 10λ0 and 20λ0, respectively, where λ0=0.8μm is the laser wavelength. The corresponding pulse energy is ∼50mJ with peak power at the terawatt level. The polarization of the laser is fixed in the z-direction. When the plasma channel is matched with the laser beam, one can find that Δn=1.766×1018cm−3=10−3nc with the channel width r0=10λ0. We take the minimum density on the channel axis n0=0.25Δn. In the simulation hereafter, rc and rw are taken as 17.5λ0 and 5λ0, respectively.
