• Optics and Precision Engineering
  • Vol. 33, Issue 7, 1042 (2025)
Shoutong WANG1, Ran ZHANG1、2、*, Jinkui CHU1、2, Hailong MENG1, and Dehao CAI1
Author Affiliations
  • 1Liaoning Provincial Key Laboratory of Micro Nanosystems, Dalian University of Technology, Dalian6024, China
  • 2Ningbo Research Institute, Dalian University of Technology, Ningbo31500, China
  • show less
    DOI: 10.37188/OPE.20253307.1042 Cite this Article
    Shoutong WANG, Ran ZHANG, Jinkui CHU, Hailong MENG, Dehao CAI. Full-stokes photodetector based on neural networks[J]. Optics and Precision Engineering, 2025, 33(7): 1042 Copy Citation Text show less

    Abstract

    Traditional Full-Stokes detection methods are based on time-division or spatial-division approaches, which suffer from drawbacks such as large device size, challenging integration, and inability to detect consistently in space and time. Recent advancements in two-dimensional materials and metamaterials have made it possible to realize ultracompact, spatiotemporally coherent Full-Stokes detectors based on well-defined polarization-sensitive structures at subwavelength scales. This study proposes a polarization detector based on graphene-metal nanoantennas, which leverages vector photocurrents generated on graphene and a neural network algorithm for reconstruction, enabling spatiotemporally coherent Full-Stokes parameter detection. Vector photocurrents under different polarization states of incident light were obtained through FDTD simulations. Subsequently, a mapping relationship S^=f(I^) between the Full-Stokes parameters S^ and the recorded vector photocurrents I^ was established using a neural network algorithm, successfully enabling the detection of Full-Stokes parameters. At a wavelength of 4 μm, the mean square error was 0.007 69. The relative radius difference of the minimum enclosing spheres for the actual and predicted Stokes parameters of the incident light is 7.68%. This detector design offers a new approach for achieving more integrated and miniaturized spatiotemporally coherent Full-Stokes detection. This detector effectively overcomes the inherent technical bottlenecks of time-division and spatial-division mechanisms, offering a novel approach for achieving more integrated and miniaturized spatiotemporally consistent full-Stokes detection.
    Shoutong WANG, Ran ZHANG, Jinkui CHU, Hailong MENG, Dehao CAI. Full-stokes photodetector based on neural networks[J]. Optics and Precision Engineering, 2025, 33(7): 1042
    Download Citation
