Abstract
Solar-driven photocatalytic water splitting is regarded as one of the most promising clean and sustainable methods for hydrogen production,often referred to as "solar fuel generation from water". Approximately 43% of solar energy lies within the visible spectrum,driving the urgent need for efficient,durable,and cost-effective visible-light-responsive catalysts for hydrogen production[
Previous studies have explored element doping and defect engineering to address these challenges. Element doping involves incorporating elements such as carbon,oxygen,sulfur,or fluorine into BNNS to modify its band structure and enhance photocatalytic performance[
High-energy ionizing radiation has been identified as an effective tool for catalyst modifications. As early as the 1960s,researchers such as Clarke[
Inspired by previous work on radiation-induced exfoliation for BNNS preparation[
1 Materials and methods
1.1 Reagents
Hexagonal boron nitride (h-BN,analytical grade) was purchased from Aladdin Biochemical Technology Co.,Ltd.,Shanghai,China. Isopropanol,methanol,sodium sulfite,sodium sulfate,and triethanolamine were obtained from Sinopharm Chemical Reagent Co.,Ltd. and were all of the analytical grade. Deionized water was used throughout the experiments.
1.2 Methods
Preparation of BNNS: BNNS was prepared via a ball-milling method. One gram of h-BN powder was placed in a zirconia ball milling jar,and the milling parameters are shown in
Gamma-ray irradiation experiments: One hundred milligrams of BNNS were dispersed ultrasonically in a mixed solvent of deionized water (15 mL) and isopropanol (5 mL),purged with nitrogen and sealed. The sample was irradiated with a Co-60 gamma-ray source (5.5×10¹⁴ Bq,located at the University of Science and Technology of China) at a dose rate of 62 Gy/min for different times. After irradiation,the sample was centrifuged and washed three times with deionized water,followed by vacuum freeze-drying (-50 ℃,6 Pa) to obtain the product.
1.3 Characterization
1.3.1 Morphology characterization
The morphology of the samples was characterized by transmission electron microscopy (TEM,Hitachi H7650,operating voltage: 100 kV). Atomic force microscopy (AFM,Veeco,MultiMode V) was used to determine the accurate thickness and lateral dimensions.
1.3.2 Defect structure characterization
The defect structure of the samples was analyzed using electron paramagnetic resonance (EPR) spectroscopy,measured with a JEOL JES-FA200 EPR spectrometer (9.081 GHz).
1.3.3 Crystal structure characterization
The crystal structure of the samples was characterized by X-ray diffraction (XRD),using a high-resolution X-ray diffractometer (Rigaku TTRIII,Cu Kα, λ=0. 154 18 nm,8 (°)/min,20°-70°).
1.3.4 Spectral characterization
Fourier transform infrared (FTIR) spectra were obtained using a Thermo Fisher Nicolet 6700 spectrometer (4 000~400 cm-1) with the KBr pellet method. Ultraviolet-visible (UV-vis) absorption and diffuse reflectance spectra (DRS) were measured using a Shimadzu UV-3600 spectrophotometer. Steady-state fluorescence spectra and fluorescence decay curves were measured with a steady-state-transient fluorescence spectrometer (JY Fluorolog-3-Tou) with an excitation wavelength of 400 nm.
1.3.5 Electrochemical tests
Photoelectrochemical tests,including photocurrent curves,Mott-Schottky plots,and electrochemical impedance spectroscopy (EIS),were conducted using an electrochemical workstation (CHI660E). A three-electrode configuration was used: platinum foil (counter electrode),Ag/AgCl electrode (reference electrode),and BNNS-coated ITO conductive glass (working electrode,1 cm×1 cm). A xenon lamp (Perfect Light PLS-SXE 300,≥420 nm,300 W) was used as the light source. The electrolyte was 0.5 mol/L saturated sodium sulfate solution.
1.3.6 Photocatalytic performance testing
Five milligrams of irradiated BNNS were dispersed in 40 mL of deionized water,and 5 mL of methanol was added as a sacrificial agent. The system was purged with argon and sealed. A xenon lamp (Perfect Light PLS-SXE 300,≥420 nm,300 W) was used as the light source,and the gaseous products were analyzed using gas chromatography (SHIMADZU GC-2014,Ar).
2 Results and discussion
2.1 Morphological characterization of ball-milled BNNS
The morphology and thickness of h-BN before and after ball milling are shown in
![]()
Figure 1.TEM image of the raw h-BN (a); TEM image (b) and AFM image (c) of BNNS; the corresponding height (d) and horizontal length (e) histograms from AFM image; N2 adsorption-desorption isotherms of raw h-BN (f) and BNNS (g) (the inset: the pore size distribution determined using the BJH method based on the adsorption isotherms)
2.2 Chemical structure of BNNS after gamma-ray irradiation
The FTIR spectra (
![]()
Figure 2.FTIR (a),XRD (b),and EPR (c) spectra of BNNS under different absorbed doses irradiation (color online)
The EPR spectra indicated the formation of defects in the irradiated samples (
![]()
Figure 3.The curves of transformed Kubelka-Munk function versus photon energy (the inset: corresponding UV-vis DRS spectra) (a),Mott-Schottky plots (b),and band structure alignments (c) of BNNS under different absorbed doses irradiation (color online)
Furthermore,apart from the alternations in band structures,radiation-induced defects also impacted the separation dynamics of photogenerated carriers (
![]()
Figure 4.Photoluminescence spectra (a) and transient fluorescence decay curves (b) of BNNS under different absorbed doses irradiation (color online)
2.3 Photocatalytic hydrogen production performance
The visible-light photocatalytic performance of irradiated BNNS was evaluated through hydrogen evolution from water splitting (
![]()
Figure 5.Photocatalytic hydrogen evolution (a) and cycling curves (b) of BNNS under different absorbed doses irradiation; the yields of gas products in the photocatalytic reaction by irradiated BNNS (absorbed dose: 133 kGy); transient photocurrent response (d) and electrochemical impedance spectra (e) of BNNS under different absorbed doses (color online)
Table Infomation Is Not EnableBeyond hydrogen,methane and carbon monoxide were also detected among the gaseous products,originating from methanol decomposition. This demonstrates that irradiated BNNS can simultaneously decompose methanol and water,broadening its potential applications in clean energy fields. Furthermore,as shown in
Electrochemical analyses investigated the interfacial charge transport behavior of BNNS before and after visible-light irradiation. Transient photocurrent characterization revealed that irradiated BNNS exhibited a sensitive response during light on-off cycles,with photocurrent intensity increasing alongside the absorbed dose (
These findings demonstrate that gamma-ray radiation-induced TBC defects effectively overcame the inherent limitations of BNNS in visible-light-driven catalytic applications. First,the introduction of defects established intermediate energy levels,enabling visible light absorption. Second,the defects shifted the CBB potential to more negative one,thereby enhancing the reduction potential of photogenerated electrons and thermodynamically favoring photocatalytic reactions. Third,the defects facilitated the separation of photogenerated carriers,minimizing recombination losses. Finally,the partial incorporation of defects improved interfacial charge transfer efficiency,solidifying the potential of irradiated BNNS for advanced photocatalytic application under visible light.
3 Conclusion
This study presents a novel and straightforward approach utilizing high-energy ionizing radiation to introduce defects in BNNS and achieve their visible-light-responsive catalytic activity. Gamma-ray radiation-induced TBC defects introduced intermediate energy levels into BNNS,effectively narrowing the bandgap from 5.3 eV to 2.7 eV and facilitating visible light absorption. Electrochemical analyses confirmed that these TBC defects promoted efficient separation and rapid migration of photogenerated carriers,resulting in exceptional hydrogen evolution performance. The irradiated BNNS achieved a maximum hydrogen production rate of 1 033.7 μmol/(g·h),nearly two orders of magnitude greater than BNNS synthesized via conventional methods. This innovative defect engineering strategy provides a promising pathway for developing efficient photocatalysts.
More importantly,this work highlights the potential of radiation technology in designing defect-rich structures for other wide-bandgap materials,potentially catalyzing groundbreaking advances in their catalytic performance. Such advancements position this approach as a key highlight of radiation chemistry following the study of polymer radiation effects[
References
[1] Hisatomi T, Kubota J, Domen K. Recent advances in semiconductors for photocatalytic and photoelectrochemical water splitting[J]. Chemical Society Reviews, 43, 7520-7535(2014).
[2] Zou X X, Zhang Y. Noble metal-free hydrogen evolution catalysts for water splitting[J]. Chemical Society Reviews, 44, 5148-5180(2015).
[3] Wang L, Xu X Z, Zhang L N et al. Epitaxial growth of a 100-square-centimetre single-crystal hexagonal boron nitride monolayer on copper[J]. Nature, 570, 91-95(2019).
[4] Watanabe K, Taniguchi T, Kanda H. Direct-bandgap properties and evidence for ultraviolet lasing of hexagonal boron nitride single crystal[J]. Nature Materials, 3, 404-409(2004).
[5] Huang C J, Chen C, Zhang M W et al. Carbon-doped BN nanosheets for metal-free photoredox catalysis[J]. Nature Communications, 6, 7698(2015).
[6] Lei W W, Zhang H, Wu Y et al. Oxygen-doped boron nitride nanosheets with excellent performance in hydrogen storage[J]. Nano Energy, 6, 219-224(2014).
[7] Babu P, Mohanty S, Naik B et al. Synergistic effects of boron and sulfur co-doping into graphitic carbon nitride framework for enhanced photocatalytic activity in visible light driven hydrogen generation[J]. ACS Applied Energy Materials, 1, 5936-5947(2018).
[8] Xing F S, Liu Q W, Song M X et al. Fluorine modified boron carbon nitride semiconductors for improved photocatalytic CO2 reduction under visible light[J]. ChemCatChem, 10, 5270-5279(2018).
[9] Attaccalite C, Bockstedte M, Marini A et al. Coupling of excitons and defect states in boron-nitride nanostructures[J]. Physical Review B, 83, 144115(2011).
[10] Liu Q W, Chen C, Du M et al. Porous hexagonal boron nitride sheets: effect of hydroxyl and secondary amino groups on photocatalytic hydrogen evolution[J]. ACS Applied Nano Materials, 1, 4566-4575(2018).
[11] Chagoya K L, Nash D J, Jiang T et al. Mechanically enhanced catalytic reduction of carbon dioxide over defect hexagonal boron nitride[J]. ACS Sustainable Chemistry & Engineering, 9, 2447-2455(2021).
[12] Liu Z K, Yan B, Meng S Y et al. Plasma tuning local environment of hexagonal boron nitride for oxidative dehydrogenation of propane[J]. Angewandte Chemie International Edition, 60, 19691-19695(2021).
[13] Clarke R W, Gibson E J. Effect of ionizing radiation on solid catalysts[J]. Nature, 180, 140-141(1957).
[14] Barry T I, Roberts R. Effect of gamma-radiation on the synthesis of methanol over zinc oxide[J]. Nature, 184, 1061-1062(1959).
[15] Cropper W H. Radiation effects on the reactivity of solid surfaces: defects produced in solids by radiation fields can enter into chemical reactions on the surface[J]. Science, 137, 955-961(1962).
[16] Baru V G. Effect of irradiation on the adsorption and catalytic properties of semiconductors and dielectrics[J]. Russian Chemical Reviews, 32, 590-604(1963).
[17] Spinks J W T, Woods R J[M]. An introduction to radiation chemistry, 442-452(1990).
[18] Wu D Z, Ge X W, Zhang Z C et al. Novel one-step route for synthesizing CdS/polystyrene nanocomposite hollow spheres[J]. Langmuir, 20, 5192-5195(2004).
[19] Wang W K, Wu Y H, Jiang Z W et al. Formation mechanism of 3D macroporous graphene aerogel in alcohol-water media under gamma-ray radiation[J]. Applied Surface Science, 427, 1144-1151(2018).
[20] Wang W K, Wu Y H, Jiang Z W et al. Self-assembly of graphene oxide nanosheets in t-butanol/water medium under gamma-ray radiation[J]. Chinese Chemical Letters, 29, 931-934(2018).
[21] Zhang Q, Jiang Z W, Wang M Z et al. Gamma ray radiation effect on Bi2WO6 photocatalyst[J], 31, 701-706(2018).
[22] Jiang Z W, Zhu W G, Xu G Q et al. Ni-nanoparticle-bound boron nitride nanosheets prepared by a radiation-induced reduction-exfoliation method and their catalytic performance[J]. Journal of Materials Chemistry A, 8, 9109-9120(2020).
[23] Wu Z H, Shen H, Wang Y et al. Enhancing mechanical property,thermal conductivity,and radiation stability of fluorine rubber through incorporation of hexagonal boron nitride nanosheets[J]. Polymer Composites, 45, 11659-11672(2024).
[24] JIANG Zhiwen. Preparation,modification,and applications of boron nitride nanosheets[D](2021).
[25] Huang B, Lee H. Defect and impurity properties of hexagonal boron nitride: a first-principles calculation[J]. Physical Review B, 86, 245406(2012).
[26] Weston L, Wickramaratne D, Mackoit M et al. Native point defects and impurities in hexagonal boron nitride[J]. Physical Review B, 97, 214104(2018).
[27] McDougall N L, Partridge J G, Nicholls R J et al. Influence of point defects on the near edge structure of hexagonal boron nitride[J]. Physical Review B, 96, 144106(2017).
[28] Cataldo F, Iglesias-Groth S. Neutron damage of hexagonal boron nitride: h-BN[J]. Journal of Radioanalytical and Nuclear Chemistry, 313, 261-271(2017).
[29] Toledo J R, de Jesus D B, Kianinia M et al. Electron paramagnetic resonance signature of point defects in neutron-irradiated hexagonal boron nitride[J]. Physical Review B, 98, 155203(2018).
[30] Xing X L, Zhang M, Hou L L et al. Z-scheme BCN-TiO2 nanocomposites with oxygen vacancy for high efficiency visible light driven hydrogen production[J]. International Journal of Hydrogen Energy, 42, 28434-28444(2017).
[31] Zhu C, Liu C A, Fu Y J et al. Construction of CDs/CdS photocatalysts for stable and efficient hydrogen production in water and seawater[J]. Applied Catalysis B: Environmental, 242, 178-185(2019).
[32] He Y Q, Xu N, Junior L B et al. Construction of AuNPs/h-BN nanocomposites by using gold as interfacial electron transfer mediator with highly efficient degradation for levofloxacin hydrochloride and hydrogen generation[J]. Applied Surface Science, 520, 146336(2020).
[33] Li M Z, Wang Y O, Tang P et al. Graphene with atomic-level in-plane decoration of h-BN domains for efficient photocatalysis[J]. Chemistry of Materials, 29, 2769-2776(2017).
[34] Chen L Y, Zhou M, Luo Z S et al. Template-free synthesis of carbon-doped boron nitride nanosheets for enhanced photocatalytic hydrogen evolution[J]. Applied Catalysis B: Environmental, 241, 246-255(2019).
[35] Shi X, Wang W, Miao X R et al. Constructing conductive channels between platinum nanoparticles and graphitic carbon nitride by gamma irradiation for an enhanced oxygen reduction reaction[J]. ACS Applied Materials & Interfaces, 12, 46095-46106(2020).
[36] Wang W, Zhao X M, Shi H T et al. Shape inducer-free polygonal angle platinum nanoparticles in graphene oxide as oxygen reduction catalyst derived from gamma irradiation[J]. Journal of Colloid and Interface Science, 575, 1-15(2020).
