• Laser & Optoelectronics Progress
  • Vol. 62, Issue 2, 0237006 (2025)
Rufei Liu1、*, Weibin Xu1, Qianying Zhao2, and Zhanwen Su1
Author Affiliations
  • 1College of Geodesy and Geomatics, Shandong University of Science and Technology, Qingdao 266590, Shandong , China
  • 2Qingdao Geology and Minerals Rock and Soil Engineering Co., Ltd., Qingdao 266072, Shandong , China
  • show less
    DOI: 10.3788/LOP241089 Cite this Article Set citation alerts
    Rufei Liu, Weibin Xu, Qianying Zhao, Zhanwen Su. Adaptive Descent Distance Cloth Simulation Algorithm for Pavement Pothole Extraction[J]. Laser & Optoelectronics Progress, 2025, 62(2): 0237006 Copy Citation Text show less

    Abstract

    Aiming at the problem that the traditonal cloth simulation filtering (CSF) algorithm cannot distinguish the local microtopography of pavement damage, which leads to the wrong detection and omission of pothole damages, an adaptive descend distance CSF algorithm for pavement pothole extraction is proposed. First, the proposed algorithm preprocesses and denoises the point cloud of the road to obtain the pavement point cloud. Second, by improving the displacement distance of the"external force drop"and"internal force pull back"processes of the simulated cloth in the CSF algorithm, the adaptive distance drop of the simulated cloth is realized, and then further constructs the accurate local datum plane of the road surface and generates the depth-enhanced information model of the point cloud. Finally, depth threshold classification and Euclidean clustering algorithm are used to achieve precise detection of potholes and extract geometric attribute features of potholes. Experiments and analysis of the measured road data show that, the recall of potholes in the measured data reaches 83.3%, and the precision reaches 87.5%, the maximum relative error of area is 17.699%, and the maximum relative error of depth is 9.677%, which has a certain degree of robustness and applicability. The proposed algorithm can provide a powerful support for the work of large-scale three-dimensional pavement point cloud data for the automatic and precise detection of potholes on pavements.
    Rufei Liu, Weibin Xu, Qianying Zhao, Zhanwen Su. Adaptive Descent Distance Cloth Simulation Algorithm for Pavement Pothole Extraction[J]. Laser & Optoelectronics Progress, 2025, 62(2): 0237006
    Download Citation
