- Advanced Photonics
- Vol. 6, Issue 3, 035001 (2024)
Abstract
1 Introduction
Microcavity lasing has many excellent properties, such as a small mode volume, high quality factor (Q), high sensitivity, effortless manipulation, and good monochromaticity, which can be applied in sensing,1
Surface plasmon polaritons (SPPs) propagate at the interface between a metal conductor and dielectric in the form of electromagnetic waves20 and can constrain and manipulate optical signals in subwavelength structures over long distances. Because of the limitations of the surface boundary conditions, only the transverse magnetic (TM) polarization mode surface waves of the SPPs can propagate at the metal–air interface. The unique properties of the SPPs provide an effective method for separating and selecting the polarization modes of lanthanide-based microlasers. However, traditional mode selection methods such as reducing cavity size, increasing mode selection structure, and Vernier efficacy-based methods, which adjust the laser mode by reducing the number of modes, cannot effectively select the laser polarization mode, and compared with pure silicon-based devices used for polarization beam splitters,21 SPP-based devices provide a compact size and a remote-control interface for on-chip applications.22
In this letter, a simple and effective plasmon-assisted mode selection method for a lanthanide-based whispering gallery mode (WGM) microlaser is proposed. A plasmon-assisted lanthanide-based microcavity composed of a silver microplate is used as a substrate, on which a UCNP-coated () microsphere is placed. Compared with lanthanide-based microlasers, the transverse electric (TE) mode lasing of plasmon-assisted lanthanide microlasers can be selectively enhanced by the enhanced local electric field and long-distance propagation of plasmons. Meanwhile, under the near-field excitation of SPPs, lasing mode splitting can be observed owing to the coherent coupling between the microcavity and mirror microcavity modes. The remote excitation and control of upconversion microlasing can also be achieved by propagating SPPs. The proposed mode-selection method has promising prospects for on-chip optoelectronic devices, encrypted optical information transmission, and high-precision sensors.
Sign up for Advanced Photonics TOC. Get the latest issue of Advanced Photonics delivered right to you!Sign up now
2 Results and Discussion
In this letter, a plasmon-assisted mode selection lanthanide-based microcavity was realized by placing a single UCNP-coated microsphere on a monocrystalline silver microplate, as illustrated in Fig. 1(a). Using the UCNP-coated microspheres, WGMs could be generated through total internal reflection, facilitating whispering gallery lasing through the fluorescence of the coupled UCNPs. with diameter were synthesized using a high-temperature thermal decomposition method,25,26 as shown in Fig. 1(b) (i) and Fig. S1 in the Supplementary Material. To realize upconversion lasing, UCNPs, as gain media, were uniformly coated on the surface of the microsphere using the spin-coating method [Fig. 1(b) (ii)]. The fabricated microcavities maintained a perfectly spherical shape and smooth morphology, which effectively reduced the scattering loss in the optical resonance and spontaneous emission background, thereby guaranteeing high-quality and low-threshold laser operation. A silver microplate was placed under the fabricated microcavity as a carrier to generate propagating SPPs. As shown in Fig. 1(b) (iii), the monocrystalline silver microplates with thickness were prepared by a fast one-step synthesis in a water solution at room temperature, as reported in our previous study.27,28 These microplates are characterized by their low ohmic loss, long-distance transmission SPPs, SPP distribution, and mode adjustment properties.29 Subsequently, the micromanipulation technique was used to transfer an individual microsphere onto a specific silver microplate, and the microcavity used for plasmon-assisted mode selection was successfully constructed. Figure 1(c) illustrates the physical mechanism of the plasmon-assisted mode-selection microlaser, in which the fluorescence of resonated in the microcavity, resulting in lasers with two different polarization modes. The TM mode of the laser propagated on the surface of the microplate because the SPPs of the silver microplate could only support TM mode propagation. The reserved TE mode was further resonance-enhanced in the microcavity and amplified by the local electromagnetic field of the plasmons. Therefore, the selective enhancement of TE mode lasing was realized.
Figure 1.(a) Schematic diagram of the plasmon-assisted mode selection lanthanide-based microcavity. (b) Transmission electron microscope image of (i)
First, we investigated the characteristics of upconversion lasing from a single microcavity. Figure 1(d) displays the upconversion fluorescence spectra of UCNPs and a microcavity with a diameter of under the 976-nm continuous-wave laser excitation. The blue curve depicts the fluorescence peak of the UCNPs at 803 nm, corresponding to the upconversion emission from the to energy level. When the doping concentration of increases to 2% with 20% as the sensitizer, ion has a large absorption cross section for 976 nm and absorbs photon energy to transfer to ion (activator), ion absorbs photon energy to reach different excited states , , , and levels, and a highly excited ion transfers a fraction of its energy to a neighboring ion in its ground state, resulting in two ions in the same intermediate excited state. The enhanced cross-relaxation of (, ), (, , ) and (, , ) will facilitate population inversion at the intermediate state of and amplify the corresponding 803-nm emission for upconversion lasing.13 The red curve depicts the efficient upconversion lasing of the TM and TE multimode mixtures produced by the UCNPs coupled to the microcavity. The lasing corresponding to the fluorescence emission peak at 803 nm of the UCNPs shows a narrow linewidth and high efficiency, which demonstrates the excellent laser emission characteristics of the constructed microcavity.
The emission spectra were monitored at various excitation powers to confirm the generation of microlasing and characterize its behavior. In Fig. 2(a), the red and blue point plots represent the pumping power-dependent plots for the integrated emission intensity and spectral linewidth of the 802-nm lasing peak, respectively. The emission intensity is calculated by integrating the lasing peak, which exhibits a sharply increasing slope as the laser power increases, corresponding to a lasing threshold; the spectral linewidth narrows sharply at the lasing threshold, which proves the generation of a low-threshold and narrow-linewidth microlaser. To investigate the polarization anisotropy of the microlaser and distinguish between the TM and TE modes, the fluorescence emission spectra of the microlaser were collected at different polarization angles. In Fig. 2(b), the red triangles and blue spheres denote the polarization-dependent intensities of the 788- and 802-nm lasing, respectively, representing linear polarization-dependent emission vertically and horizontally. The polarization at 788 nm corresponds to the collected polarization angle of 90 deg, which corresponds to TM mode lasing. The 802-nm lasing corresponds to TE mode lasing owing to the lasing action, exhibiting strong polarization with the dominant optical feedback path perpendicular to the equatorial plane of the microcavity. The Q factor and full width at half-maximum (FWHM) of the 788- and 802-nm lasing were investigated while altering the polarization angle and were also found to be orthogonal (Fig. S2 in the Supplementary Material). It should be noted that the FWHM of the lasing lines 802 nm could reach a narrowness of 0.35 nm for these microspheres, while Q factors on the order of 2500 were estimated based on these precise FWHM measurements.
Figure 2.(a) Pumping power-dependent plots of emission intensities and spectral linewidth narrowing of 802-nm lasing on the glass substrate exhibiting upconversion lasing emissions. (b) Polarization investigation of the 788- and 802-nm lasing lines using a polar plot of the intensities; the fitting curves were drawn by a cosine-square function.
Based on the high-efficiency narrow-linewidth upconversion lasing, a single lanthanide-based microcavity was placed on a single silver microplate using a micromanipulation transfer technique to realize plasmon-assisted mode selection. As shown in the upper left of Fig. 3(a), a lanthanide-based microcavity was successfully transferred onto a silver microplate. The fluorescence emission spectra of the microsphere were measured before and after transfer onto a silver microplate. The TE mode exhibited significant enhancement on the silver microplate compared with that on glass, as shown in Fig. 3(a). By contrast, no noticeable intensity changes were observed for TM mode lasing. The microcavity, combined with the silver microplate, exhibited a polarization beam-splitting effect, and the TE mode could be selected and enhanced. We further verified the validity of the plasmon-assisted mode selection by adding polarizers to the collection optical path and setting the polarization parallel to the microsphere radial to 0 deg. Polarization lasing perpendicular to the radial polarization of the microsphere was mainly observed when the polarization of the collection was 90 deg, corresponding to TM mode lasing. As shown in Fig. 3(b), the TM mode lasing intensity was slightly stronger than that of the full-space collection in Fig. 3(a), and the TE mode lasing intensity was slightly weaker. The TM polarization collection experiment weakened the function of plasmon mode selection but proved the effectiveness of plasmon-assisted TE mode selection. Furthermore, the slight blueshift observed in the lasing compared with the simulation results could be attributed to the change of distribution of UCNPs on the surface of the microsphere when the microcavity was transferred onto the silver microplate using the optical fiber tip and the change of the surrounding environment of the microcavity during the micromanipulation process.
Figure 3.(a) Fluorescence emission spectra of
To reveal the mechanism of the plasmon-assisted TE mode selection, an electromagnetic field analysis of the silver microplate-coupled microcavity was performed. A point dipole source with a wavelength of 800 nm was used to represent the fluorescence emission of the UCNPs, which was placed at the position of the strongest electric field in the silver microplate and microcavity coupling system for subsequent simulation. We first simulated the far-field radiation spectra of the dipole source in the microcavity and silver microplate-coupled microcavity, as shown in Fig. 3(c). The black line represents the far-field radiation spectrum of the dipole source in the microcavity, and the intensities of each pair of the TE and TM modes are equal. The red line represents the far-field radiation of the dipole source in the silver microplate-coupled microcavity. The overall intensity of the TE and TM modes was enhanced relative to the dipole source in the microcavity, whereas the TM mode intensity was weaker than the TE mode intensity. The results showed the same TE mode selection effect as that in the experiment. We further simulated the charge distribution on the silver microplate surface using a microcavity-coupled silver microplate system. Because the fluorescence of UCNPs has no polarization characteristics, the luminescence of UCNPs was simulated using different dipole electric field orientations. We defined the axis along the radial direction of the microsphere, the axis perpendicular to the paper surface, and the axis horizontally along the tangential direction of the microsphere. As shown in Fig. 3(d) (i), when the (dipole field oriented in the direction) dipole excited the microlaser, the lasing TM mode was transmitted on the silver microplate by the SPPs. When the dipole excited the microlaser, a significantly weak charge distribution was observed. When the -stimulated WGM was stimulated, as shown in Fig. 3(d) (iii), a portion of the SPP transmission phenomenon was observed, as the excited electric field contained components in the direction of the TM, and part of the dipole energy was transmitted by SPPs on the silver microplate. The dipole-TM directional component could also be transmitted as SPPs on a silver microplate, as demonstrated when simulating the charge distribution on a silver microplate with a single dipole placed in the same position without a microcavity (Fig. S7 in the Supplementary Material). Interestingly, we found that both and transmitted SPPs owing to the TM component because the polar coordinates of the dipole electric field orientation and polar coordinates of the silver microplate had a certain angle, so the direction of the two polar coordinates was parallel, and the and directions have a certain angle; consequently, the electric fields in the and directions include the TM component. However, on the silver microplate, only transmitted SPPs on the right side, and the left side could not transmit SPPs because of the presence of the microcavity. Because the TM mode of the excitation microlaser is weak, it is believed that the SPPs generated by excitation on the silver microplate were caused by the dipole source itself. Therefore, the TM mode lasing on the silver microplate was significantly weakened compared with that of the TE mode. The intensities of the TE and TM modes were compared using the spectral data in Fig. 3(a) and the simulation in Fig. 3(c) for a more intuitive and clear comparison (see Table S1 in the Supplementary Material). As shown in the table, the intensity ratio between the TE and TM modes on the silver microplate was always larger than that on the glass substrate for both the experiment and simulation. The experimental and simulation results show that the selective enhancement of the TE mode can be achieved using a plasmon-assistant method. On the one hand, the fluorescence emission of UCNPs coupled with a microcavity is amplified by the local electromagnetic field effect of plasmons; on the other hand, the SPPs of silver microplates can support the propagation of TM mode lasing and weaken the intensity of TM mode lasing.
The lasing mode was also split on the silver microplate when investigating plasmon-assisted mode selection. As shown in Fig. 4(a), the TE mode lasing peak at 798 nm splits into two peaks. We represent the modes of these two peaks as modes 1 and 2. Polarization-dependent spectra were collected to distinguish between the two modes. As shown in Fig. 4(b), when the polarization was collected at 0 deg, the right peak was dominant, whereas when collected at 90 deg, the left peak prevailed. The intensities of the split left and right peaks were compared, resulting in a drafted table (see Table S2 in the Supplementary Material). The intensity ratio of modes 1 and 2 changed from 1.43 at 0 deg to 0.63 at 90 deg, indicating that the polarizations of modes 1 and 2 were orthogonal. Interestingly, the plasmon-assisted microlaser was different from the conventional WGM microlaser when a mirror microcavity was introduced by the silver microplate, and the two microcavity modes were coherently coupled to form two orthogonal modes, as shown in Fig. 4(a), resulting in the phenomenon of modes 1 and 2 splitting.30 To explain the mechanism by which the microsphere creates a mirror cavity on the silver microplate and splits the lasing peaks, we used a two-sphere system to simulate the electric field distribution profile (see Fig. S13 in the Supplementary Material). Dipoles with different orientations were placed between the two spheres owing to coupling with the second microsphere once the degenerate mode was split into two different modes. Polarization degeneracy in excitation lifted, and modes 1 and 2 were excited using orthogonal input polarizations. Both modes exhibited a continuous total internal reflection along the periphery of the sphere. Because the input polarizations of the excited modes were orthogonal, the outcoupled radiation preserved this orthogonality.
Figure 4.(a) Enlarged view of the lasing mode peak near 798 nm on the silver microplate. (b) Fluorescence spectrum of the corresponding lasing peak in panel (a) when the polarizer in the collected optical path was at 0 and 90 deg.
In addition to inducing lasing mode selection, SPPs propagating over long distances on a silver microplate also present an opportunity for remote manipulation of microlasers. As shown in the bright-field image in Fig. 5(a), the red circle represents the excitation position, and (in deg) represents the polarization angle of the excitation light. When the edge of a silver microplate is excited by a laser with a suitable polarization angle, the SPPs propagating to the microcavity can be excited by edge-side scattering to provide momentum-matching conditions, and the microlaser can be excited remotely. It is evident from the spectrum that lasing excitation was observed. The lasing reached its peak intensity at an excitation polarization angle of [Fig. 5(b)], which could be attributed to the polarization characteristics of the SPP excitation. The propagation intensity of the SPPs is positively correlated with the vertical component of the electric vector,27 with the SPP excitation exhibiting maximum strength when the excitation polarization is perpendicular to the edge of the silver microplate. This plasmon-assisted microlaser system enables investigations into mixed nonlinear nanophotonics and monomolecular remote-sensing applications.
Figure 5.(a) Bright-field microscopy image of a microlaser remotely excited by SPPs. The red and blue circles represent the excitation and collection positions, respectively. The angle
3 Conclusion
In summary, we designed a simple and effective plasmon-assisted lanthanide-based microcavity that achieved TE polarization mode-selective enhancement and remote lasing excitation. Selective enhancement of the TE polarization mode was achieved through the introduction of local electromagnetic field amplification and the assistance of SPPs propagating on the surface of a silver microplate. Meanwhile, laser mode splitting was observed on the silver microplate owing to the coherent coupling between the microcavity and mirror microcavity modes. Moreover, because of the tens-of-micrometers long-distance propagation characteristics of SPPs on silver microplates, remote excitation and laser control were realized. These plasmon-assisted polarization-mode optional and remote-controllable upconversion microlasers hold significant potential in nonlinear hybrid nanophotonics, stochastic laser applications, and nanooptical sensing.
