Author Affiliations
1School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China2Shanghai Quantum Science Research Center, Shanghai 201315, Chinashow less
【AIGC One Sentence Reading】:基于InGaAs/InP APD设计了2GHz单光子探测器,采用正弦门控与低通滤波技术,在1310nm波段、-10℃下实现40.2%探测效率,为量子通信和量子计算提供高性能支撑。
【AIGC Short Abstract】:基于InGaAs/InP APD设计了2 GHz单光子探测器,通过正弦门控与低通滤波技术结合,有效抑制尖峰噪声并提取雪崩信号。在1310 nm波段、−10 ℃下,实现40.2%探测效率、低暗计数率与后脉冲概率、80 ps时间抖动。还分析了门控信号幅度与工作温度对性能的影响,助力远距离量子通信等应用。
Note: This section is automatically generated by AI . The website and platform operators shall not be liable for any commercial or legal consequences arising from your use of AI generated content on this website. Please be aware of this.
Abstract
As the receiving terminal for quantum information systems, improving the photon detection efficiency and working frequency of single-photon detectors holds great significance. In this paper, we present a 2 GHz high-detection-efficiency single-photon detector utilizing an InGaAs/InP avalanche photodiode (APD). By combining sinusoidally gated operation with the low-pass filtering technique, the spike noise of the APD was effectively suppressed, achieving a noise rejection ratio of 41.5 dB. With high-frequency gated operation, the detection efficiency reached 40.2% at a wavelength of 1310 nm. The afterpulse probability was 10.0%, and the dark count rate was 7.75×10-6 per gate when the APD was cooled to -10 ℃. The SPD also demonstrated excellent time resolution, with a time jitter of only 80 ps. To further improve the performance of the SPD, we adjust the amplitudes of the gate signal and operating temperatures. The presented SPD provides support for applications such as quantum communication and quantum computing.
