• Chip
  • Vol. 3, Issue 3, 100106 (2024)
Wenjie Dou1、†, Chaonan Lin1、†, Wei Fan2、†, Xun Yang1、*, Chao Fang1, Huaping Zang1, Shaoyi Wang2, Congxu Zhu3, Zhi Zheng3, Weimin Zhou2、**, and Chongxin Shan1、***
Author Affiliations
  • 1Henan Key Laboratory of Diamond Optoelectronic Material and Devices, Key Laboratory of Material Physics, Ministry of Education, School of Physics and Microelectronics, Zhengzhou University, Zhengzhou 450052, China
  • 2Science and Technology on Plasma Physics Laboratory, Laser Fusion Research Center, China Academy of Engineering Physics, Mianyang 621900, China
  • 3Key Laboratory of Micro-Nano Materials for Energy Storage and Conversion of Henan Province, College of Chemical and Materials Engineering, Xuchang University, Xuchang 461000, China
  • show less
    DOI: 10.1016/j.chip.2024.100106 Cite this Article
    Wenjie Dou, Chaonan Lin, Wei Fan, Xun Yang, Chao Fang, Huaping Zang, Shaoyi Wang, Congxu Zhu, Zhi Zheng, Weimin Zhou, Chongxin Shan. Highly sensitive diamond X-ray detector array for high-temperature applications[J]. Chip, 2024, 3(3): 100106 Copy Citation Text show less

    Abstract

    Diamond is a highly suitable material for X-ray detectors that can function effectively in harsh environments due to its unique properties such as ultrawide bandgap, high radiation resistance, excellent carrier mobility as well as remarkable chemical and thermal stability. However, the sensitivity of diamond X-ray detectors needs further improvement due to the relatively low X-ray absorption efficiency of diamond, and the exploration of single-crystal diamond array imaging still remains unexplored. In the current work, a 10 × 10 X-ray photodetector array was constructed from single-crystal diamond. To improve the sensitivity of the diamond X-ray detector, an asymmetric sandwich electrode structure was utilized. Additionally, trenches were created through laser cutting to prevent crosstalk between adjacent pixels. The diamond X-ray detector array exhibits exceptional performance, including a low detection limit of 4.9 nGy s-1, a sensitivity of 14.3 mC Gy-1 cm-2, and a light-dark current ratio of 18,312, which are among the most favorable values ever reported for diamond X-ray detectors. Furthermore, these diamond X-ray detectors can operate at high temperatures up to 450 °C, making them suitable for development in harsh environments.
    Wenjie Dou, Chaonan Lin, Wei Fan, Xun Yang, Chao Fang, Huaping Zang, Shaoyi Wang, Congxu Zhu, Zhi Zheng, Weimin Zhou, Chongxin Shan. Highly sensitive diamond X-ray detector array for high-temperature applications[J]. Chip, 2024, 3(3): 100106
