• Optics and Precision Engineering
  • Vol. 32, Issue 14, 2189 (2024)
Tongqin RAN1, Fu WAN1,2,*, Quan ZHOU1,2, Weiping KONG1..., Qiang LIU1, Yingkai LONG3 and Weigen CHEN1,2|Show fewer author(s)
Author Affiliations
  • 1State Key Laboratory of Power Transmission Equipment Technology, School of Electrical Engineering, Chongqing University, Chongqing400044, China
  • 2National Innovation Center for Industry-Education Integration of Energy Storage Technology, Chongqing University, Chongqing400044, China
  • 3State Grid Chongqing Electric Power Company Chongqing Electric Power Research Institute, Chongqing40112, China
  • show less
    DOI: 10.37188/OPE.20243214.2189 Cite this Article
    Tongqin RAN, Fu WAN, Quan ZHOU, Weiping KONG, Qiang LIU, Yingkai LONG, Weigen CHEN. Design of automatic image measuring system Research on dynamic and high-sensitive detection of SF6 discharge decomposition products by fluorescence-suppressed fiber-enhanced Raman spectroscopy[J]. Optics and Precision Engineering, 2024, 32(14): 2189 Copy Citation Text show less

    Abstract

    Analyzing the dynamic change of composition and concentration of SF6 discharge decomposition products is the key to SF6 Gas-Insulated Switchgear (GIS) state diagnosis. This paper proposed a dynamic and high-sensitive detection method based on fluorescence-suppressed Fiber-Enhanced Raman Spectroscopy (FERS). Firstly, a fluorescence-suppressed FERS gas detection system of SF6 discharge decomposition products is established. With a Synergistic Fluorescence Filtering method combining CCD digital noise filtering and iris noise reduction, the signal-to-noise ratio of the system is increased by 228.4%. Based on Allan variance analysis, the optimal integration time of the system is determined to be 220 s. Next, by analyzing standard mixed gas samples under 2 bar pressure and 220 s integration time, the characteristic Raman peaks for qualitative and quantitative analysis of SF6 discharge decomposition products SOF2, SO2F2, COS, CF4, SO2, CO2 and CO are determined, and the lower limits of detection are calculated to be 1.95, 1.78, 0.83, 2.41, 0.93, 2.51, 6.69 ppm, respectively. Finally, by a 168-hour continuous partial discharge experiment in a reduced scale GIS model, the fluorescence-suppressed FERS gas detection system is proved capable of dynamic and high-sensitive detection of SF6 discharge decomposition products, and the deviation from gas chromatography result is within ±5%. Experimental results demonstrate that the proposed detection method can provide technical support for the safe operation of GIS.
    Tongqin RAN, Fu WAN, Quan ZHOU, Weiping KONG, Qiang LIU, Yingkai LONG, Weigen CHEN. Design of automatic image measuring system Research on dynamic and high-sensitive detection of SF6 discharge decomposition products by fluorescence-suppressed fiber-enhanced Raman spectroscopy[J]. Optics and Precision Engineering, 2024, 32(14): 2189
