• Optics and Precision Engineering
  • Vol. 32, Issue 18, 2744 (2024)
Yang JIANG1,*, Dongxu ZHAO2, Xiyao SONG1,3, Yiqi GU4..., Yan XING1 and Bo ZHENG5|Show fewer author(s)
Author Affiliations
  • 1Changchun Institute of Optics,Fine Mechanics and Physics,Chinese Academy of Sciences , Changchun30033,China
  • 2Guangdong-Hong Kong-Macao Joint Laboratory for Intelligent Micro-Nano Optoelectronic College of Physics and Optoelectronic Engineering, Foshan University, Foshan58000,China
  • 3University of Chinese Academy of Sciences,Beijing100049,China
  • 4China-Japan Union Hospital of Jilin University, Changchun130033,China
  • 5Guangdong Polytechnic of Science and Technology, Zhuhai19090,China
  • show less
    DOI: 10.37188/OPE.20243218.2744 Cite this Article
    Yang JIANG, Dongxu ZHAO, Xiyao SONG, Yiqi GU, Yan XING, Bo ZHENG. Design of NIR-II imaging system with wide spectrum[J]. Optics and Precision Engineering, 2024, 32(18): 2744 Copy Citation Text show less

    Abstract

    To address the demand for in vivo small animal fluorescence imaging in the near-infrared II (NIR-II) window, as well as solve the problem of simultaneous reuse of multiple wavelengths within a wide spectral range. This study took the perspective of aberration correction and designed an optical system by iteratively refining the lens group structure based on aberration curves. The working distance was increased through reasonable focal length distribution, and the glass material selection was optimized to balance chromatic aberration control and energy transmittance within the wide spectral range. The final optical structure ended up with a focal length of 40 mm, capable of ensuring MTF>0.6@34 lp/mm for the NIR-II spectral band (0.9~2.3 μm) within the working distance range (200~600 mm), with RMS spot size smaller than the pixel size (15 μm) and distortion less than 1% across the entire field of view. Real-shot tests with resolution targets demonstrate a resolution capability of 50 μm. This optical design provides a solution based on all-glass spherical lenses capable of meeting the requirements for high-quality, low detection threshold in vivo small animal fluorescence imaging in the NIR-II window.
    Yang JIANG, Dongxu ZHAO, Xiyao SONG, Yiqi GU, Yan XING, Bo ZHENG. Design of NIR-II imaging system with wide spectrum[J]. Optics and Precision Engineering, 2024, 32(18): 2744
