• Journal of Applied Optics
  • Vol. 45, Issue 5, 1019 (2024)
Wujun LYU1, Sen HAN1,2,*, Jidong XU2, Yuhang SHEN1..., Linghua ZHANG1,2, Ying YANG1 and Jingming GUO1|Show fewer author(s)
Author Affiliations
  • 1School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • 2Suzhou H & L Instruments LLC., Suzhou 215123, China
  • show less
    DOI: 10.5768/JAO202445.0503004 Cite this Article
    Wujun LYU, Sen HAN, Jidong XU, Yuhang SHEN, Linghua ZHANG, Ying YANG, Jingming GUO. Spectrum analysis of low frequency vibration in interferometry[J]. Journal of Applied Optics, 2024, 45(5): 1019 Copy Citation Text show less

    Abstract

    In order to reduce the influence of vibration on phase-shifting interferometry, the spectrum analysis of the vibration signal was carried out to separate the spectrum signal that contributed to the low-frequency vibration, which verified the fact that the phase-shifting interferometry (PSI) algorithm was more sensitive to vibration at 2 times the phase-shifting frequency. According to the standard PSI measurement steps and Newton's generalized binomial theorem, the multi-frequency vibration influence factor γ was derived. The phase error calculated by the standard PSI algorithm and the phase error after the multi-frequency vibration influence factor γ processing were simulated by Matlab software, and the experiment was carried out to verify it. The results show that the RMS value and phase error of the wavefront processed by the γ influence factor are lower than those of the PSI algorithm. The RMS value can be reduced by 22 times and the phase error can be reduced by 20 times.
    Wujun LYU, Sen HAN, Jidong XU, Yuhang SHEN, Linghua ZHANG, Ying YANG, Jingming GUO. Spectrum analysis of low frequency vibration in interferometry[J]. Journal of Applied Optics, 2024, 45(5): 1019
