• Nano-Micro Letters
  • Vol. 16, Issue 1, 009 (2024)
Shengbo Zhang1,2, Yuankang Zha1,2, Yixing Ye1,2, Ke Li3,*..., Yue Lin4, Lirong Zheng5, Guozhong Wang1,2, Yunxia Zhang1,2, Huajie Yin1,2, Tongfei Shi1,2,** and Haimin Zhang1,2,***|Show fewer author(s)
Author Affiliations
  • 1Laboratory of Materials Physics, Centre for Environmental and Energy Nanomaterials, Anhui Key Laboratory of Nanomaterials and Nanotechnology, CAS Center for Excellence in Nanoscience, Institute of Solid State Physics, HFIPS, Chinese Academy of Sciences, Hefei 230031, People’s Republic of China
  • 2University of Science and Technology of China, Hefei, 230026, People’s Republic of China
  • 3Key Laboratory of Agricultural Sensors, Ministry of Agriculture, School of Information and Computer, Anhui Agricultural University, Hefei 230026, People’s Republic of China
  • 4Hefei National Research Center for Physical Sciences at the Microscale, University of Science and Technology of China, Hefei 230026, People’s Republic of China
  • 5Beijing Synchrotron Radiation Facility, Institute of High Energy Physics, Chinese Academy of Sciences, 19B Yuquan Road, Beijing 100049, People’s Republic of China
  • show less
    DOI: 10.1007/s40820-023-01217-z Cite this Article
    Shengbo Zhang, Yuankang Zha, Yixing Ye, Ke Li, Yue Lin, Lirong Zheng, Guozhong Wang, Yunxia Zhang, Huajie Yin, Tongfei Shi, Haimin Zhang. Oxygen-Coordinated Single Mn Sites for Efficient Electrocatalytic Nitrate Reduction to Ammonia[J]. Nano-Micro Letters, 2024, 16(1): 009 Copy Citation Text show less

    Abstract

    Electrocatalytic nitrate reduction reaction has attracted increasing attention due to its goal of low carbon emission and environmental protection. Here, we report an efficient NitRR catalyst composed of single Mn sites with atomically dispersed oxygen (O) coordination on bacterial cellulose-converted graphitic carbon (Mn–O–C). Evidence of the atomically dispersed Mn–(O–C2)4 moieties embedding in the exposed basal plane of carbon surface is confirmed by X-ray absorption spectroscopy. As a result, the as-synthesized Mn–O–C catalyst exhibits superior NitRR activity with an NH3 yield rate (RNH3) of 1476.9 ± 62.6 μg h-1 cm-2 at - 0.7 V (vs. reversible hydrogen electrode, RHE) and a faradaic efficiency (FE) of 89.0 ± 3.8% at - 0.5 V (vs. RHE) under ambient conditions. Further, when evaluated with a practical flow cell, Mn–O–C shows a high RNH3 of 3706.7 ± 552.0 μg h-1 cm-2 at a current density of 100 mA cm-2, 2.5 times of that in the H cell. The in situ FT-IR and Raman spectroscopic studies combined with theoretical calculations indicate that the Mn–(O–C2)4 sites not only effectively inhibit the competitive hydrogen evolution reaction, but also greatly promote the adsorption and activation of nitrate (NO3-), thus boosting both the FE and selectivity of NH3 over Mn–(O–C2)4 sites.
    Shengbo Zhang, Yuankang Zha, Yixing Ye, Ke Li, Yue Lin, Lirong Zheng, Guozhong Wang, Yunxia Zhang, Huajie Yin, Tongfei Shi, Haimin Zhang. Oxygen-Coordinated Single Mn Sites for Efficient Electrocatalytic Nitrate Reduction to Ammonia[J]. Nano-Micro Letters, 2024, 16(1): 009
