As mobile communication devices proliferate and industries, such as artificial intelligence and big data rapidly expand, optical communication systems have seen a significant surge in capacity. This has necessitated the use of various multiplexing technologies to boost the transmission capabilities of optical networks. Wavelength division multiplexing (WDM) stands out as the most cost-effective and efficient method to enhance communication capacity without altering the existing network infrastructure. However, the operational wavelength range of WDM is constrained by the gain bandwidth of the employed optical amplifiers.1^,2 The erbium-doped fiber amplifier (EDFA) is the go-to optical amplifier in WDM systems, even though its gain bandwidth covers only a fraction of the low-loss window of standard single-mode fibers.3 Raman fiber amplifiers, which theoretically offer a broader gain bandwidth, have not gained widespread use in WDM systems due to their higher pump power requirements, leading to substantial system power consumption.4^,5 Consequently, developing optical amplifiers that offer both wide bandwidth and low-power-consumption is critical for enhancing the transmission capacity of optical communication networks.

Moreover, with on-chip photonic devices becoming increasingly integral to everyday life, on-chip optical interconnect systems also demand amplifiers that provide both large bandwidth and low-power-consumption, similar to the requirements of broader optical communication networks. Given the successful deployment of EDFA in optical networks, it seems logical to consider the erbium-doped waveguide amplifier (EDWA) for on-chip interconnect systems. However, EDWA necessitates a higher rare-earth doping concentration ($\sim {10}^{21}{\mathrm{cm}}^{-3}$) in the host material due to its compact size, which not all materials can accommodate without issues, such as devitrification or reduced ion activity due to concentration quenching.6^,7 High-concentration doping also increases the likelihood of cross-relaxation-induced upconversion luminescence, which can diminish the gain in the communication band. Thus, identifying host materials that can support high rare-earth doping levels and maintain excellent luminescence properties is a key research area for on-chip optical waveguide amplifiers. Researchers have experimented with various materials, including crystal substances, such as ${\mathrm{Er}}^{3+}$-doped lithium niobate,8^,9${\mathrm{Si}}_3{\mathrm{N}}_4$,10^,11 and ${\mathrm{Y}}_2{\mathrm{O}}_3$,12 glass materials such as silicate,13^,14 chalcogenide,15^–17 and fluoride,18^,19 and polymers, such as PMMA20^,21 and PPMA.22 Due to their broad bandwidth, isotropic properties, ease of fabrication, and superior thermal stability, ${\mathrm{Er}}^{3+}$-doped glasses have emerged as the preferred host materials for on-chip optical waveguide amplifiers. Among these glasses, amorphous ${\mathrm{Al}}_2{\mathrm{O}}_3$ is viewed as an outstanding candidate, due to its high ${\mathrm{Er}}^{3+}$ doping capacity (up to $\sim 4.9\times {10}^{21}{\mathrm{cm}}^{-3}$),23^,24 extensive transparent window from ultraviolet (UV) to mid-infrared (150 to 5500 nm), and minimal optical loss [$(0.04\pm 0.02)\mathrm{dB}/\mathrm{cm}$ in C-band].25 Furthermore, ${\mathrm{Al}}_2{\mathrm{O}}_3$ can be readily deposited on wafers using various techniques26^–30 and is compatible with silicon photonics processing.

However, the relatively low refractive index of ${\mathrm{Al}}_2{\mathrm{O}}_3$ and its modest contrast with ${\mathrm{SiO}}_2$ cladding have led to efforts to enhance its refractive index to improve light confinement and device integration in compact spaces.31 This has been achieved by synthesizing high-concentration ${\mathrm{Er}}^{3+}$-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass, with the addition of ${\mathrm{La}}^{3+}$ not only increasing the refractive index but also preventing Er ion clustering and reducing concentration quenching.32 Systematic studies indicate that this glass offers an optimal ${\mathrm{Er}}^{3+}$ doping level ($5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}44{\mathrm{La}}_2{\mathrm{O}}_3\text{-}51{\mathrm{Al}}_2{\mathrm{O}}_3$) and exhibits promising luminescence characteristics, making it an excellent host material for optical waveguide amplifiers. However, the challenge of upconversion luminescence consuming a significant portion of the pump power remains, as evidenced by the high pump threshold in the C-band. To address this, ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}$ co-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass has been developed, leveraging ${\mathrm{Yb}}^{3+}$’s larger absorption cross section to reduce power consumption significantly. Despite these advancements, the gain bandwidth of ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}$ co-doped glass remains narrow, a limitation dictated by the electronic configuration of ${\mathrm{Er}}^{3+}$ ions.

To broaden the gain bandwidth further, ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass has been designed and synthesized. The introduction of ${\mathrm{Tm}}^{3+}$ is strategic, as it offers two prominent near-infrared (NIR) emission bands that, combined with ${\mathrm{Er}}^{3+}$’s emissions, are expected to yield an ultrawide gain bandwidth. This work establishes a foundation for the development of low-power, ultrabroadband on-chip waveguide amplifiers, presenting new opportunities for advancing short-range optical interconnect systems.

Glasses triply doped with ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ in the composition $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}x{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}(44\text{-}x){\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ ($x=0$, 0.2, 0.4, 0.6, 1, 2) were synthesized using the aerodynamic levitation (ADL) technique. The precursor materials, ${\mathrm{Er}}_2{\mathrm{O}}_3$, ${\mathrm{Yb}}_2{\mathrm{O}}_3$, ${\mathrm{Tm}}_2{\mathrm{O}}_3$, ${\mathrm{La}}_2{\mathrm{O}}_3$, and ${\mathrm{Al}}_2{\mathrm{O}}_3$, all of high purity (99.99%), were measured and mixed according to the stoichiometric ratios of the desired glass composition. The mixed oxides were then pressed into pellets $\sim 10\mathrm{mm}$ in diameter and $\sim 2\mathrm{mm}$ thick. These pellets were sintered into a glass phase in a muffle furnace at 1650°C and subsequently quenched at 1800°C using ADL technology. Further details on the preparation process are available in our previously published works.6^,32^–34 The optical properties of the glasses were characterized using a UV-Vis-NIR spectrometer (Lambda 950, PerkinElmer, Waltham, Massachusetts) for absorption spectra and a fluorescence spectrophotometer (FLS1000, Edinburgh, United Kingdom) for emission spectra. The glass transition temperature ($T_g$) was determined with a differential scanning calorimeter (STA 449 F3, Netzsch).

Figure 1 presents the schematic of the proposed low-power-consumption, ultrawideband on-chip optical waveguide amplifier. The active region of the amplifier utilizes the newly developed and synthesized ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass. This glass outperforms the previously favored rare-earth-doped ${\mathrm{Al}}_2{\mathrm{O}}_3$ as a host material for on-chip optical waveguide amplifiers due to its higher refractive index, attributed to the high content of lanthanide elements with larger relative atomic masses. The increased refractive index enhances the waveguide’s light-confinement capabilities, enabling the integration of longer waveguides within the compact chip dimensions, thereby facilitating higher gain.

The incorporation of ${\mathrm{Yb}}^{3+}$ ions, which exhibit strong absorption at the commercially available 980 nm laser wavelength, allows the waveguide amplifier to achieve efficient absorption and utilization of the pump light. This results in high gain with low pump power, epitomizing the low-power-consumption design goal. Furthermore, the co-doping with ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ ions enable NIR broadband luminescence, with ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ known for their excellent luminescence $\sim 1535$ and $\sim 1860\mathrm{nm}$, respectively. Consequently, the optical waveguide amplifier designed with ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass is expected to deliver ultrawideband NIR gain with minimal power requirements.

Figure 2(a) displays a photograph of the ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass samples, all of which appear crystal clear without any visible scattering that would indicate crystallization. This clarity suggests that the rapid cooling facilitated by the ADL technology was effective in converting all the samples into a glassy state.

As depicted in Fig. 2(b), the absorption spectra of the samples were analyzed. It is well established that the intensities of the absorption peaks at $\sim 525$, 550, 660, and 1535 nm, corresponding to the transitions of ${\mathrm{Er}}^{3+}$ from the ${{}^4\mathrm{I}}_{15/2}$ ground state to the ${{}^2\mathrm{H}}_{11/2}$, ${{}^4\mathrm{S}}_{3/2}$, ${{}^4\mathrm{F}}_{9/2}$, and ${{}^4\mathrm{I}}_{13/2}$ excited states, respectively, remain relatively unchanged. This is attributed to the consistent ${\mathrm{Er}}_2{\mathrm{O}}_3$ content across the samples. Similarly, the absorption peak at around 980 nm, associated with the transitions ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{15/2}\to {{}^4\mathrm{I}}_{11/2}$ and ${\mathrm{Yb}}^{3+}:{{}^2\mathrm{F}}_{7/2}\to {{}^2\mathrm{F}}_{5/2}$, shows no significant variation in intensity due to the constant ${\mathrm{Yb}}_2{\mathrm{O}}_3$ content, mirroring the stability of the ${\mathrm{Er}}_2{\mathrm{O}}_3$ content.

In contrast, the absorption peak at $\sim 1211\mathrm{nm}$, which is solely attributed to the ${\mathrm{Tm}}^{3+}:{{}^3\mathrm{F}}_4\to {{}^3\mathrm{H}}_5$ transition, exhibits a gradual increase in intensity with the rising content of ${\mathrm{Tm}}_2{\mathrm{O}}_3$. The behavior of these characteristic peaks indicates that the samples possess a high degree of compositional accuracy. Further insights into the transitions of ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ ions, their implications will be discussed subsequently.

The photoluminescence spectra of the glasses with the composition $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}x{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}(44\text{-}x){\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$, where $x$ varies from 0 to 2, were recorded under excitation with a 980 nm laser (refer to Fig. 3). Pronounced luminescence peaks are observed in both the upconversion spectra, ranging from 400 to 900 nm, and the downconversion spectra, spanning 2500 to 3000 nm [as shown in Figs. 3(a) and 3(b)]. These peaks correspond to the transitions of ${\mathrm{Er}}^{3+}:{{}^2\mathrm{H}}_{11/2}\to {{}^4\mathrm{I}}_{15/2}$, ${{}^4\mathrm{S}}_{3/2}\to {{}^4\mathrm{I}}_{15/2}$, ${{}^4\mathrm{F}}_{9/2}\to {{}^4\mathrm{I}}_{15/2}$, ${{}^4\mathrm{I}}_{9/2}\to {{}^4\mathrm{I}}_{15/2}$, and ${{}^4\mathrm{I}}_{11/2}\to {{}^4\mathrm{I}}_{13/2}$, manifesting as luminescence at $\sim 525$, 550, 660, 808, and 2700 nm. These luminescence peaks correlate with the absorption peaks identified in Fig. 2(b). Notably, the intensity of the peaks at $\sim 660$ and $\sim 2700\mathrm{nm}$, which are typically of high intensity, exhibit a significant reduction upon the introduction of ${\mathrm{Tm}}_2{\mathrm{O}}_3$. Given that these wavelengths are not associated with ${\mathrm{Tm}}^{3+}$ transitions, the marked decrease in luminescence intensity with increasing ${\mathrm{Tm}}_2{\mathrm{O}}_3$ content suggests the presence of intricate energy transfer (ET) processes between ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ ions. These processes will be further elucidated later in the text.

Moreover, it is important to highlight that the observed diminishment in both upconversion and downconversion luminescence intensities, particularly at $\sim 2700\mathrm{nm}$, contrasts with the previously reported enhancement in upconversion luminescence due to high-concentration ${\mathrm{Er}}^{3+}$ doping. The tri-doping of ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ in the ${\mathrm{La}}_2{\mathrm{O}}_3-{\mathrm{Al}}_2{\mathrm{O}}_3$ matrix leads to a concurrent weakening of both upconversion and downconversion luminescence, indicative of stronger NIR luminescence and improved pump utilization efficiency. This characteristic is highly advantageous for the development of low-power, high-gain NIR on-chip optical waveguide amplifiers.

The photoluminescence spectra of the ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ samples are presented in the NIR band, ranging from 1400 to 2100 nm, as shown in Fig. 3(c). As anticipated, the ${\mathrm{Er}}_2{\mathrm{O}}_3\text{-}{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}{\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glasses exhibit intense NIR luminescence, which is several orders of magnitude stronger than both the upconversion and downconversion luminescence around $\sim 2700\mathrm{nm}$. Moreover, it is evident that with increasing ${\mathrm{Tm}}_2{\mathrm{O}}_3$ content, the emission peak at $\sim 1535\mathrm{nm}$, attributable to the ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{13/2}\to {{}^4\mathrm{I}}_{15/2}$ transition, diminishes, while the emission peak at $\sim 1860\mathrm{nm}$, associated with the ${\mathrm{Tm}}^{3+}:{{}^3\mathrm{F}}_4\to {{}^3\mathrm{H}}_6$ transition, intensifies. This observation reinforces the presence of an ET process between ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ ions. The interplay of these two emission peaks contributes to an ultrawide luminescence bandwidth in the NIR spectrum. Specifically, the luminescence spectrum of the glass composition $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ spans an impressive range of $\sim 478\mathrm{nm}$, from $\sim 1510$ to $\sim 1988\mathrm{nm}$, as shown in Fig. 3(d). Furthermore, the concentrations of ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ in the material are $\sim 1.56\times {10}^{21}$, $\sim 1.56\times {10}^{21}$, and $\sim 6.25\times {10}^{19}{\mathrm{cm}}^{-3}$, respectively, exhibit rare-earth ion solubility comparable to ${\mathrm{Al}}_2{\mathrm{O}}_3$, meeting the demands of matrix materials for on-chip waveguide amplifiers. This suggests that an on-chip optical waveguide amplifier based on this material could potentially offer ultrawideband gain—a feature typically achieved only with ultrahigh power pumped Raman amplifiers in the past.

The energy level diagram of ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ ions is utilized to elucidate the ultrabroadband luminescence mechanism in ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glasses under 980 nm laser excitation and to explicate the ET processes among these ions (refer to Fig. 4). It is well established that ${\mathrm{Yb}}^{3+}$ ions exhibit a larger absorption cross section for 980 nm light compared to ${\mathrm{Er}}^{3+}$ ions, while ${\mathrm{Tm}}^{3+}$ ions have negligible absorption at this wavelength, a characteristic dictated by the distribution of energy levels in rare-earth ions. Consequently, when ${\mathrm{Er}}_2{\mathrm{O}}_3\text{-}{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}{\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass is pumped with a 980 nm laser, the majority of the pump photons are absorbed by ${\mathrm{Yb}}^{3+}$ ions, followed by ${\mathrm{Er}}^{3+}$ ions, with ${\mathrm{Tm}}^{3+}$ absorption being insignificant. Upon absorbing 980 nm photons, electrons in the ground state of ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{15/2}$ and ${\mathrm{Yb}}^{3+}:{{}^2\mathrm{F}}_{7/2}$ are excited to the ${{}^4\mathrm{I}}_{11/2}$ and ${{}^2\mathrm{F}}_{5/2}$ levels, respectively. Given the short average lifetime of electrons in the ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{11/2}$ excited state, they typically transition to the lower energy state ${{}^4\mathrm{I}}_{13/2}$, emitting photons around $\sim 2700\mathrm{nm}$. However, achieving luminescence at $\sim 2700\mathrm{nm}$ is challenging in practice, as the ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{11/2}\to {{}^4\mathrm{I}}_{13/2}$ transition is a self-terminating process that requires materials with a high ${\mathrm{Er}}^{3+}$ doping concentration, moderate phonon energy, and low OH^– concentration.33^,35 Electrons at the ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{11/2}$ level usually undergo multiphonon relaxation to the ${{}^4\mathrm{I}}_{13/2}$ level, and eventually transition to the ground state ${{}^4\mathrm{I}}_{15/2}$, releasing photons with a wavelength of $\sim 1535\mathrm{nm}$. In materials with higher ${\mathrm{Er}}^{3+}$ doping concentrations, energy upconversion (ETU) and excited state absorption (ESA) processes become more probable due to the reduced distance between ${\mathrm{Er}}^{3+}$ ions. ETU and ESA lead to the excitation of more electrons to higher energy states, which, in turn, enhances upconversion luminescence due to the shorter average lifetimes of these higher excited states. This is why materials doped with high concentrations of ${\mathrm{Er}}^{3+}$ are typically more effective as hosts for upconversion luminescence.

As previously noted, ${\mathrm{Yb}}^{3+}$ ions more readily absorb pump light than ${\mathrm{Er}}^{3+}$ ions, exciting electrons from the ground state ${{}^2\mathrm{F}}_{7/2}$ to the higher energy state ${{}^2\mathrm{F}}_{5/2}$. Typically, ${\mathrm{Yb}}^{3+}$ is considered to have only these two energy levels. Within the ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glass, electrons in the high energy state ${{}^2\mathrm{F}}_{5/2}$ of ${\mathrm{Yb}}^{3+}$ transfer energy to corresponding energy levels of ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$, leading to a reversal in the population of these levels, as shown in Fig. 4. These ETs enhance the luminescence of ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ and improve the pump light utilization efficiency. In addition to energy being transferred from the excited ${\mathrm{Yb}}^{3+}$ ions to ${\mathrm{Tm}}^{3+}$ ions, ET also occurs between ${\mathrm{Er}}^{3+}$ and ${\mathrm{Tm}}^{3+}$, as illustrated in the figure. Electrons in ${\mathrm{Tm}}^{3+}:{{}^3\mathrm{F}}_2$, which achieve population inversion through ET processes, transition to $3{\mathrm{H}}_4$ via multiphonon relaxation, and then further transition to ${{}^3\mathrm{F}}_4$ while emitting photons at $\sim 1470\mathrm{nm}$. Along with the electrons transitioning from ${\mathrm{Tm}}^{3+}:{{}^3\mathrm{H}}_5$ to ${{}^3\mathrm{F}}_4$ through multiphonon relaxation, electrons at this level eventually transition to the ground state ${{}^3\mathrm{H}}_6$, emitting photons at $\sim 1860\mathrm{nm}$. This explains why the ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped material can emit light at $\sim 1470$ and $\sim 1860\mathrm{nm}$, even though ${\mathrm{Tm}}^{3+}$ does not absorb the 980 nm pump light. However, the photoluminescence spectra presented earlier in this article indicate a reduction in the upconversion and downconversion luminescence of ${\mathrm{Er}}^{3+}$ near $\sim 2700\mathrm{nm}$, alongside an enhancement of NIR luminescence, with no significant luminescence of ${\mathrm{Tm}}^{3+}$ at $\sim 1470\mathrm{nm}$ being observed. This leads us to believe that, at least in the ${\mathrm{Er}}_2{\mathrm{O}}_3\text{-}{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}{\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glasses, the ET processes among ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$ predominantly occur among lower energy levels, such as ET1, ET2, ET3, and ET4. This is highly advantageous for achieving NIR luminescence and will greatly benefit the use of this material in low-power-consumption NIR on-chip optical waveguide amplifiers.

The Judd–Ofelt (J-O) theory is commonly employed to determine the spectral parameters of rare-earth-doped materials, which in turn are used to assess the luminescence properties of these materials. To explore the potential of $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass as a host material for on-chip optical waveguide amplifiers, J-O theory is applied to calculate the transition probability ($A_R$) and branching ratio (${\beta }_R$) of the material. Eleven absorption bands in the absorption spectrum are used to fit the transition strength parameters ${\mathrm{\Omega }}_t$ ($t=2$, 4, 6), which correspond to the optical transitions of ${\mathrm{Er}}^{3+}$ ions from the ground state ${{}^4\mathrm{I}}_{15/2}$ to various excited states. The spectral parameters of the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass are presented and summarized in Table 1. This includes the experimental oscillator strength ($f_{\exp \mathrm{.}}$), the calculated oscillator strength ($f_{\mathrm{cal}\mathrm{.}}$), the experimental electric dipole line strength ($S_{\exp \mathrm{.}}$), and the calculated electric dipole line strength ($S_{\mathrm{cal}\mathrm{.}}$). The relative square deviation between the measured and calculated electric-dipole oscillator strengths is used as a measure of the fitting quality ($R$), which can be expressed by $$R=\left\{\frac{\sum (f_{\mathrm{exp.}}-f_{\mathrm{cal.}}{)}^2}{\sum f_{\mathrm{exp.}}^2}\right\}.$$(1)

This equation quantifies the discrepancy between the experimental and theoretical values, providing insight into the accuracy of the J-O theory in predicting the luminescence properties of the material in question.

The $R$ value represents the square deviation between experimental and theoretical oscillator strengths, serving as an indicator of the fitting quality. The J-O intensity parameters (${\mathrm{\Omega }}_2$, ${\mathrm{\Omega }}_4$, and ${\mathrm{\Omega }}_6$) for the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass are $0.901\times {10}^{-20}$, $1.056\times {10}^{-20}$, and $0.943\times {10}^{-20}{\mathrm{cm}}^2$, respectively. These parameters are indicative of the local environment and the nature of bonding around the rare-earth ions. ${\mathrm{\Omega }}_2$, in particular, is highly sensitive to the local environment of rare-earth ions, reflecting the asymmetry of the coordination structure, bonding characteristics, and polarizability of the ligand ions or molecules. The relatively small value of ${\mathrm{\Omega }}_2$ for the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass suggests a higher symmetry in the coordination structure around ${\mathrm{Er}}^{3+}$ ions and denotes a high degree of material uniformity.

Radiative properties, such as the radiative transition probability ($A_R$), stimulated emission cross section ($\sigma$), and branching ratio (${\beta }_R$) for the excited state of ${\mathrm{Er}}^{3+}$ are calculated based on the J-O parameters previously obtained and are summarized in Table 2. For the detailed calculation equations, readers are referred to the literature.36^–38

Compared to the $A_R$ of $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}44{\mathrm{La}}_2{\mathrm{O}}_3\text{-}51{\mathrm{Al}}_2{\mathrm{O}}_3$ glass ($125.46{\mathrm{s}}^{-1}$), the $A_R$ of $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass ($173.74{\mathrm{s}}^{-1}$) for the ${{}^4\mathrm{I}}_{13/2}\to {{}^4\mathrm{I}}_{15/2}$ transition is higher. This suggests that the incorporation of ${\mathrm{Yb}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ enhances the luminescence in the NIR band. Furthermore, the branching ratio ${\beta }_R$ for the ${{}^4\mathrm{I}}_{11/2}\to {{}^4\mathrm{I}}_{13/2}$ transition is 21.3%, which is lower than that of the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}44{\mathrm{La}}_2{\mathrm{O}}_3\text{-}51{\mathrm{Al}}_2{\mathrm{O}}_3$ glass. This indicates that the introduction of ${\mathrm{Yb}}^{3+}$ and ${\mathrm{Tm}}^{3+}$ leads to a decrease in luminescence at $\sim 2700\mathrm{nm}$, a finding corroborated by the photoluminescence spectrum presented earlier in this article. This also reflects the accuracy of the parameters calculated using J-O theory and the potential for low power consumption when using this material to achieve NIR luminescence.

To further verify the low-power-consumption characteristics of the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass in the ultrawideband NIR band, the absorption and emission cross -sections around $\sim 1535$ and $\sim 1860\mathrm{nm}$ were calculated for the transitions ${\mathrm{Er}}^{3+}:{{}^4\mathrm{I}}_{13/2}\to {{}^4\mathrm{I}}_{15/2}$ and ${\mathrm{Tm}}^{3+}:{{}^3\mathrm{F}}_4\to {{}^3\mathrm{H}}_6$, respectively. The absorption cross section (${\sigma }_{\mathrm{abs}}$) is determined from the measured absorption spectrum using the Beer–Lambert law, as given by $${\sigma }_{\mathrm{abs}}(\lambda )=\frac{\alpha (\lambda )}{N},$$(2)where $\alpha (\lambda )$ is the absorption coefficient at wavelength $\lambda$. The emission cross section (${\sigma }_{\mathrm{em}}$) is determined using the Fuchtbauer–Ladenburg (F-L) model, as given by$${\sigma }_{\mathrm{em}}(\lambda )=\frac{{\lambda }^4{A}_{\mathrm{rad}}}{8\pi c{n}^2}\frac{\lambda I(\lambda )}{\int \lambda I(\lambda )\mathrm{d}\lambda },$$(3)where $A_{\mathrm{rad}}$ is the radiative transition probability, $n$ is the refractive index, and $I(\lambda )$ is the measured fluorescence emission intensity at wavelength $\lambda$. The calculated absorption and emission cross sections are shown below.

The calculated absorption and emission cross sections clearly indicate that the emission cross sections near $\sim 1535$ and $\sim 1860\mathrm{nm}$ are substantially larger than the absorption cross sections, as shown in Figs. 5(a) and 5(b), suggesting the potential for significant gains within these bands. Moreover, by integrating the obtained emission and absorption cross sections, the gain cross section for the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass was calculated by $$G(\lambda )=P·{\sigma }_{\mathrm{em}}(\lambda )-(1-P)·{\sigma }_{\mathrm{abs}}(\lambda ).$$(4)

Here, $P$ represents the population inversion of ${\mathrm{Er}}^{3+}$ or ${\mathrm{Tm}}^{3+}$, defined as $P=N_2/(N_2+N_1)$, where $N_1$ and $N_2$ are the population densities of the ground and excited states, respectively. The gain spectra around $\sim 1535$ and $\sim 1860\mathrm{nm}$ for the $5{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass, as depicted in Fig. 6, show that as $P$ increases, the bandwidth encompassed by the positive gain spectrum also expands. It is evident from the results that the gain transitions from negative to positive as $P$ rises. A positive gain is achievable in both spectral bands when $P>0.2$, indicating that minimal pump power is required to achieve gain, thus confirming the material’s low power consumption. Notably, as the positive gain intensifies, its bandwidth correspondingly broadens. These spectral properties unequivocally establish that the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass possesses characteristics of low power consumption and ultrawideband gain, making it an exemplary host material for the energy-efficient, ultrawideband, on-chip optical waveguide amplifiers.

For a host material to be suitable for low-power-consumption ultrawideband on-chip optical waveguide amplifiers, it must exhibit not only exceptional spectral characteristics but also outstanding thermal stability, especially since high-power lasers will be confined within a material of limited size. To this end, we analyzed the thermal properties of the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass using differential scanning calorimetry (DSC). The DSC curve, obtained at a heating rate of 20°C/min and depicted in Fig. 7, reveals the glass transition temperature ($T_g$) and the onset crystallization temperature ($T_x$) to be $\sim 842°\mathrm{C}$ and 962°C, respectively.

When compared to current contenders for on-chip optical waveguide amplifiers, such as silicate, tellurite, fluoride, chalcogenide glasses, and polymers, the high $T_g$ of the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass suggests superior thermal stability. Furthermore, the difference between $T_x$ and $T_g$, denoted as $\mathrm{\Delta }T$, is commonly used to assess a material’s glass-forming ability. With a $\mathrm{\Delta }T$ of 120°C, this glass demonstrates robust thermal resistance to crystallization. This characteristic provides a solid foundation for the fabrication of high-quality amorphous films of $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$, which are essential for on-chip optical waveguide amplifiers. In general, producing thin films with uniform elemental distribution, akin to bulk materials, is challenging. However, a larger $\mathrm{\Delta }T$ expands the temperature window for deposition techniques such as single-target magnetron sputtering, pulsed laser deposition (LPD), multitarget magnetron sputtering, and atomic layer deposition (ALD), thereby enabling the fabrication of high-quality multicomponent amorphous films. In addition, the elevated $T_g$, $T_x$, and larger $\mathrm{\Delta }T$ offer enhanced thermal stability during high-temperature annealing, facilitating the conversion of rare-earth metals into rare-earth ions. This process activates the absorption and emission of ${\mathrm{Er}}^{3+}$, ${\mathrm{Yb}}^{3+}$, and ${\mathrm{Tm}}^{3+}$, bringing the luminescent properties of the films and waveguides closer to those of their bulk counterparts.39^–41

The superior luminescence properties and thermal stability of the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass, as demonstrated in our study, unequivocally establish it as an ideal host material for low-power-consumption, ultrawideband on-chip optical waveguide amplifiers. This glass composition, enriched with lanthanide elements that have larger relative atomic masses compared to rare-earth-doped ${\mathrm{Al}}_2{\mathrm{O}}_3$, results in a higher refractive index. This property is advantageous for achieving high-density integration within the confined spaces of on-chip environments, as illustrated in Fig. 1. To optimize the pump light utilization efficiency, the ridge waveguide depicted in Fig. 1 was meticulously designed using COMSOL Multiphysics. The resulting waveguide dimensions are 1000 nm in width and 6000 nm in height, as shown in Fig. 8. The structural optimization took into account the confinement factors ($\mathrm{\Gamma }$) of both the pump and signal lights for the spectral bands around $\sim 1535$ and $\sim 1860\mathrm{nm}$. According to the definition by Robinson et al., the confinement factor $\mathrm{\Gamma }$ for a given mode in the active region $S$ of a high-index contrast waveguide is given by42$$\mathrm{\Gamma }=\frac{n_{\mathrm{eff}}^g}{n_S^g}\frac{{\iint }_0^Sϵ{|E(x,y)|}^2\mathrm{d}x\mathrm{d}y}{{\iint }_{-\infty }^{+\infty }ϵ{|E(x,y)|}^2\mathrm{d}x\mathrm{d}y}.$$(5)

In this equation, $n_{\mathrm{eff}}^g$ is the effective group index of the mode, $n_S^g$ is the group index of the active region $S$, $ϵ$ is the permittivity of the waveguide host material, and $E(x,y)$ represents the electric field distribution of the mode for the given cross section. Our calculations determined the confinement factors $\mathrm{\Gamma }$ for the fundamental TE-mode pump beam at 980 nm and the signal beams at 1535 and 1860 nm. The electric field distributions at these three wavelengths are depicted in the corresponding figure, yielding confinement factors of ${\mathrm{\Gamma }}_{980\mathrm{nm}}\approx 0.92$, ${\mathrm{\Gamma }}_{1535\mathrm{nm}}\approx 0.77$, and ${\mathrm{\Gamma }}_{1860\mathrm{nm}}\approx 0.65$. A higher $\mathrm{\Gamma }$ value indicates a greater overlap between the beam (pump and signal) and the active area of the waveguide, facilitating more rare-earth ions to engage in the pump absorption and signal amplification processes. Consequently, we posit that on-chip optical amplifiers based on the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass are capable of achieving low-power-consumption, ultrawideband gain.

A suite of high-concentration ${\mathrm{Er}}^{3+}\text{-}{\mathrm{Yb}}^{3+}\text{-}{\mathrm{Tm}}^{3+}$ tri-doped ${\mathrm{La}}_2{\mathrm{O}}_3\text{-}{\mathrm{Al}}_2{\mathrm{O}}_3$ glasses, intended for use as host materials in on-chip optical waveguide amplifiers, were synthesized via ADL technology. The incorporation of ${\mathrm{Tm}}_2{\mathrm{O}}_3$ led to a marked reduction in both upconversion and downconversion luminescence intensities around $\sim 2700\mathrm{nm}$. This reduction resulted in a pronounced enhancement of the glasses’ luminescence intensity within the NIR band, exhibiting an intensity 3 orders of magnitude greater than that of other bands. Furthermore, the NIR luminescence spectrum of the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass spans a broad range from $\sim 1510$ to 1988 nm, covering up to 478 nm. Calculations of absorption, emission, and gain cross sections reveal that the glass can achieve positive gain with a population inversion $P>0.2$, indicating that only low pump power is required for positive gain, thus highlighting its low-power-consumption attribute. The high glass transition temperature ($T_g$) of $\sim 842°\mathrm{C}$ and a significant $\mathrm{\Delta }T$ of $\sim 120°\mathrm{C}$ suggest outstanding thermal stability and facilitate the preparation of amorphous thin films. The combination of low pump power requirements, extensive bandwidth, superior thermal stability, and favorable glass-forming capabilities confirms that the $55{\mathrm{Er}}_2{\mathrm{O}}_3\text{-}5{\mathrm{Yb}}_2{\mathrm{O}}_3\text{-}0.2{\mathrm{Tm}}_2{\mathrm{O}}_3\text{-}43.8{\mathrm{La}}_2{\mathrm{O}}_3\text{-}46{\mathrm{Al}}_2{\mathrm{O}}_3$ glass is an exemplary host material for energy-efficient, ultrawideband on-chip optical waveguide amplifiers. This will facilitate the development and application of low-power, ultrabroadband on-chip waveguide amplifiers, providing new options for the advancement of short-range optical interconnect systems.

Biographies of the authors are not available.
