• Nano-Micro Letters
  • Vol. 16, Issue 1, 076 (2024)
Bin Li1, Pengchao Ruan2, Xieyu Xu3, Zhangxing He1,*..., Xinyan Zhu1, Liang Pan1, Ziyu Peng1, Yangyang Liu3,**, Peng Zhou4, Bingan Lu5, Lei Dai1 and Jiang Zhou2,***|Show fewer author(s)
Author Affiliations
  • 1School of Chemical Engineering, North China University of Science and Technology, Tangshan 063009, People’s Republic of China
  • 2School of Materials Science and Engineering, Central South University, Changsha 410083, People’s Republic of China
  • 3State Key Laboratory for Mechanical Behavior of Materials, Xi’an Jiaotong University, Xi’an 710049, People’s Republic of China
  • 4Hunan Provincial Key Defense Laboratory of High Temperature Wear-Resisting Materials and Preparation Technology, Hunan University of Science and Technology, Xiangtan 411201, People’s Republic of China
  • 5School of Physics and Electronics, Hunan University, Changsha 410082, People’s Republic of China
  • show less
    DOI: 10.1007/s40820-023-01278-0 Cite this Article
    Bin Li, Pengchao Ruan, Xieyu Xu, Zhangxing He, Xinyan Zhu, Liang Pan, Ziyu Peng, Yangyang Liu, Peng Zhou, Bingan Lu, Lei Dai, Jiang Zhou. Covalent Organic Framework with 3D Ordered Channel and Multi-Functional Groups Endows Zn Anode with Superior Stability[J]. Nano-Micro Letters, 2024, 16(1): 076 Copy Citation Text show less

    Abstract

    Achieving a highly robust zinc (Zn) metal anode is extremely important for improving the performance of aqueous Zn-ion batteries (AZIBs) for advancing “carbon neutrality” society, which is hampered by the uncontrollable growth of Zn dendrite and severe side reactions including hydrogen evolution reaction, corrosion, and passivation, etc. Herein, an interlayer containing fluorinated zincophilic covalent organic framework with sulfonic acid groups (COF-S-F) is developed on Zn metal (Zn@COF-S-F) as the artificial solid electrolyte interface (SEI). Sulfonic acid group (- SO3H) in COF-S-F can effectively ameliorate the desolvation process of hydrated Zn ions, and the three-dimensional channel with fluoride group (-F) can provide interconnected channels for the favorable transport of Zn ions with ion-confinement effects, endowing Zn@COF-S-F with dendrite-free morphology and suppressed side reactions. Consequently, Zn@COF-S-F symmetric cell can stably cycle for 1,000 h with low average hysteresis voltage (50.5 mV) at the current density of 1.5 mA cm-2. Zn@COF-S-F|MnO2 cell delivers the discharge specific capacity of 206.8 mAh g-1 at the current density of 1.2 A g-1 after 800 cycles with high-capacity retention (87.9%). Enlightening, building artificial SEI on metallic Zn surface with targeted design has been proved as the effective strategy to foster the practical application of high-performance AZIBs.
    Bin Li, Pengchao Ruan, Xieyu Xu, Zhangxing He, Xinyan Zhu, Liang Pan, Ziyu Peng, Yangyang Liu, Peng Zhou, Bingan Lu, Lei Dai, Jiang Zhou. Covalent Organic Framework with 3D Ordered Channel and Multi-Functional Groups Endows Zn Anode with Superior Stability[J]. Nano-Micro Letters, 2024, 16(1): 076
