• Acta Optica Sinica
  • Vol. 45, Issue 6, 0601002 (2025)
Zhengwei Qian1,2, Yu Xie1,*, Jie Chen1, Peng Wu2..., Bin Liang2, Changgong Shan2, Qianqian Zhu2, Xuan Peng2, Ye Chen1 and Wei Wang2|Show fewer author(s)
Author Affiliations
  • 1School of Advanced Manufacturing Engineering, Hefei University, Hefei 230061, Anhui , China
  • 2Key Laboratory of Environmental Optics and Technology of CAS, Anhui Institute of Optics and Fine Mechanics, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei 230031, Anhui , China
  • show less
    DOI: 10.3788/AOS241141 Cite this Article Set citation alerts
    Zhengwei Qian, Yu Xie, Jie Chen, Peng Wu, Bin Liang, Changgong Shan, Qianqian Zhu, Xuan Peng, Ye Chen, Wei Wang. Variation Characteristics of Atmospheric Methane Detected by Ground-Based High-Resolution Fourier Transform Infrared Spectroscopy[J]. Acta Optica Sinica, 2025, 45(6): 0601002 Copy Citation Text show less

    Abstract

    Objective

    Methane (CH4) is the second most important greenhouse gas in the atmosphere after carbon dioxide. Mastering precise methods for monitoring atmospheric CH4 is essential for addressing the greenhouse effect and environmental changes. This helps us better understand and predict climate change and provides policymakers with the data needed to formulate effective emission reduction measures. By accurately monitoring CH4 variations, we can identify major emission sources and assess the effectiveness of mitigation strategies, thus promoting the achievement of global climate goals.

    Methods

    We use ground-based high-resolution Fourier transform infrared (FTIR) spectroscopy to collect near-infrared solar absorption spectra. These spectra are then analyzed using a nonlinear least squares fitting algorithm to retrieve the column concentrations of atmospheric CH4 in Hefei from 2018 to 2022. Our algorithm, GFIT, is the standard retrieval method of the Total Carbon Column Observing Network (TCCON), consisting of a forward model and iterative fitting process. The forward model calculates atmospheric absorption spectra through an atmospheric radiative transfer model, combining solar parameters, atmospheric parameters, and instrument line shape parameters to generate solar absorption spectra. The iterative process then compares calculated and measured spectra, adjusting retrieval parameters to achieve the best fit. Next, we process the atmospheric CH4 concentration data monitored by FTIR spectroscopy to determine the annual growth rate of atmospheric CH4 and study its seasonal variations. We then validate the ground-based FTIR CH4 data against the TROPOspheric Monitoring Instrument (TROPOMI) satellite data. Finally, by calculating the incremental values of CH4 and carbon monoxide (CO) relative to their background values (ΔCH4 and ΔCO), we analyze the sources of atmospheric CH4 in Hefei, examining the seasonal correlations between ΔCH4 and ΔCO.

    Results and Discussions

    Our study first uses FTIR spectroscopy to investigate the variation characteristics of atmospheric CH4 in Hefei from 2018 to 2022, as shown in Figs. 2, 3, and 4. The results show an annual increase in atmospheric XCH4 in Hefei with seasonal variations, peaking in autumn and decreasing to its lowest in spring (March to April) of the following year. Second, we use ground-based CH4 data to validate TROPOMI satellite observations in Hefei, revealing good consistency between datasets, as shown in Figs. 5 and 6. The average absolute deviation between the two datasets is 5×10-9, with an average relative deviation of 0.26%, indicating a slight overestimation of CH4 column concentration by TROPOMI. Additionally, the correlation coefficient between satellite and ground-based data is 0.91, confirming TROPOMI’s high reliability in monitoring atmospheric CH4. Finally, we analyze the correlation between atmospheric CH4 and CO in Hefei to infer CH4 sources. As CO primarily originates from human activities, its correlation with CH4 can indicate the main sources of CH4. A high correlation coefficient would suggest CH4 is mainly anthropogenic, while a low correlation would suggest natural sources as the primary contributor, as shown in Fig. 7.

    Conclusions

    Atmospheric CH4 column concentrations in Hefei show a slow annual increase, with an approximate growth rate of 0.73%. The atmospheric CH4 column concentrations are lower in spring and winter, and higher in summer and autumn. Monthly averages peak in September and reach their lowest in March, at 1940×10-9 and 1890×10-9, respectively, with a seasonal variation amplitude of 50×10-9. Subsequently, we compare satellite data from the TROPOMI onboard the ESA Sentinel-5P satellite with ground-based FTIR data. The results demonstrate strong consistency between the two datasets, with an average absolute deviation of 5×10-9 and a correlation coefficient of 0.91. Finally, we conducted a correlation analysis between atmospheric CH4 and CO observed in Hefei, calculating the correlations of ΔCH4and ΔCO across four seasons over the five-year observation period from 2018 to 2022. The analysis shows a poor correlation between these gases in all seasons, suggesting that natural emissions are the primary source of atmospheric CH4 in Hefei. These findings provide effective methods for monitoring greenhouse gases in Hefei, particularly CH4, and offer valuable data support for the formulation and implementation of scientifically grounded environmental protection policies and emission reduction measures.

    Zhengwei Qian, Yu Xie, Jie Chen, Peng Wu, Bin Liang, Changgong Shan, Qianqian Zhu, Xuan Peng, Ye Chen, Wei Wang. Variation Characteristics of Atmospheric Methane Detected by Ground-Based High-Resolution Fourier Transform Infrared Spectroscopy[J]. Acta Optica Sinica, 2025, 45(6): 0601002
